Phoenix Contact 7.62mm Pitch 2 Way Right Angle Pluggable Terminal Block, Header, Through Hole, Solder Termination
- RS Stock No.:
- 254-4737
- Mfr. Part No.:
- 1806229
- Brand:
- Phoenix Contact
Available to back order for despatch 16/08/2024
Price Each (In a Pack of 50)
£2.019
(exc. VAT)
£2.423
(inc. VAT)
Units | Per unit | Per Pack* |
|---|---|---|
| 50 + | £2.019 | £100.95 |
*price indicative
- RS Stock No.:
- 254-4737
- Mfr. Part No.:
- 1806229
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- DE
Product Details
The Phoenix Contact PCB header of nominal cross section 2.5 mm² with nominal current 12 A and rated voltage (III/2) 630 V. It is male type connector. Larger pitch for increased voltage requirements.
Larger pitch for increased voltage requirements
Pitch 7.62 mm
Number of positions 2
Locking Screw locking
Pitch 7.62 mm
Number of positions 2
Locking Screw locking
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Header |
| Number of Contacts | 2 |
| Pitch | 7.62mm |
| Series | COMBICON MSTB |
| Number of Rows | 1 |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Termination Method | Solder |
