Phoenix Contact Pluggable Terminal Block, 4-Contact, 3.81 mm Pitch, 1 Row, 1827884
- RS Stock No.:
- 249-3061
- Mfr. Part No.:
- 1827884
- Brand:
- Phoenix Contact
Subtotal (1 pack of 250 units)*
£490.50
(exc. VAT)
£588.50
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 30 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 250 + | £1.962 | £490.50 |
*price indicative
- RS Stock No.:
- 249-3061
- Mfr. Part No.:
- 1827884
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 4 | |
| Pitch | 3.81mm | |
| Number of Rows | 1 | |
| Current | 8A | |
| Housing Material | Polybutylene Terephthalate | |
| Connector Gender | Male | |
| Maximum Wire Size mm² | 1.5mm² | |
| Orientation | Right Angle | |
| Colour | Green | |
| Wire Connection Method | Solder | |
| Voltage | 160V | |
| Standards/Approvals | IECEE CB Scheme, EAC, CSA, cULus Recognised | |
| Length | 9.2mm | |
| Width | 25.63mm | |
| Depth | 10.3mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 4 | ||
Pitch 3.81mm | ||
Number of Rows 1 | ||
Current 8A | ||
Housing Material Polybutylene Terephthalate | ||
Connector Gender Male | ||
Maximum Wire Size mm² 1.5mm² | ||
Orientation Right Angle | ||
Colour Green | ||
Wire Connection Method Solder | ||
Voltage 160V | ||
Standards/Approvals IECEE CB Scheme, EAC, CSA, cULus Recognised | ||
Length 9.2mm | ||
Width 25.63mm | ||
Depth 10.3mm | ||
- COO (Country of Origin):
- DE
The Phoenix Contact single row, 3.81 mm pitch, 4 positions, green printed-circuit board connector has linear pinning pin layout and 1.5 mm² nominal cross section with contact material made of Cu alloy. It has 8 A nominal current & 160 V nominal voltage.
Well-known mounting principle allows worldwide use
Screwable flange for superior mechanical stability
Maximum flexibility when it comes to device design – one header for connectors with different connection technologies
