Wurth Elektronik 2.5mm Pitch 3 Way Pluggable Terminal Block, Plug, Cable Mount
- RS Stock No.:
- 230-1945
- Mfr. Part No.:
- 691346000003B
- Brand:
- Wurth Elektronik
205 In stock - FREE next working day delivery available
Price Each (In a Box of 1000)
£1.482
(exc. VAT)
£1.778
(inc. VAT)
Units | Per unit | Per Box* |
|---|---|---|
| 1000 - 1000 | £1.482 | £1,482.00 |
| 2000 + | £1.359 | £1,359.00 |
*price indicative
- RS Stock No.:
- 230-1945
- Mfr. Part No.:
- 691346000003B
- Brand:
- Wurth Elektronik
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- TW
Product Details
The Wurth Elektronik WR-TBL PCB terminal block push-in spring connection is easy-to-maintain connector that feature a 2.5mm pitch. It used tin plated brass terminal with cable sizes in the range of 0.2-0.5mm², either solid or stranded and have a guided pi
Operating temperature -40 up to +105 °C
Insulator flammability rating UL94 V-0
Contact resistance 20 mΩ
Insulator flammability rating UL94 V-0
Contact resistance 20 mΩ
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Plug |
| Number of Contacts | 3 |
| Pitch | 2.5mm |
| Series | 3460B |
| Number of Rows | 1 |
| Mounting Type | Cable Mount |
