Wurth Elektronik WR-TBL Series Pluggable Terminal Block, 8-Contact, 3.5 mm Pitch, 1 Row
- RS Stock No.:
- 185-4361
- Distrelec Article No.:
- 301-42-590
- Mfr. Part No.:
- 691304100008
- Brand:
- Wurth Elektronik
Bulk discount available
Subtotal (1 unit)*
£7.96
(exc. VAT)
£9.55
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit |
|---|---|
| 1 - 9 | £7.96 |
| 10 - 24 | £7.17 |
| 25 - 49 | £6.50 |
| 50 - 99 | £5.96 |
| 100 + | £5.51 |
*price indicative
- RS Stock No.:
- 185-4361
- Distrelec Article No.:
- 301-42-590
- Mfr. Part No.:
- 691304100008
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 8 | |
| Pitch | 3.5mm | |
| Current | 12A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.21mm² | |
| Housing Material | Polyamide | |
| Maximum Wire Size mm² | 1.31mm² | |
| Connector Gender | Male | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 16AWG | |
| Orientation | Vertical | |
| Wire Connection Method | Screwless | |
| Colour | Green | |
| Voltage | 300V ac | |
| Series | WR-TBL | |
| Depth | 7.8mm | |
| Standards/Approvals | No | |
| Width | 21.1mm | |
| Length | 28.7mm | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 8 | ||
Pitch 3.5mm | ||
Current 12A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.21mm² | ||
Housing Material Polyamide | ||
Maximum Wire Size mm² 1.31mm² | ||
Connector Gender Male | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 16AWG | ||
Orientation Vertical | ||
Wire Connection Method Screwless | ||
Colour Green | ||
Voltage 300V ac | ||
Series WR-TBL | ||
Depth 7.8mm | ||
Standards/Approvals No | ||
Width 21.1mm | ||
Length 28.7mm | ||
- COO (Country of Origin):
- CN
WR-TBL Series 3041 - 3.50 mm Screwless Plug Vertical Entry Low Profile
