Weidmüller BL Series Pluggable Terminal Block, 16-Contact, 5.08 mm Pitch, 1 Row
- RS Stock No.:
- 176-7774
- Mfr. Part No.:
- 1943720000
- Brand:
- Weidmüller
Bulk discount available
Subtotal (1 unit)*
£9.31
(exc. VAT)
£11.17
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- 34 unit(s) shipping from 26 May 2026
- Plus 36 unit(s) shipping from 25 August 2026
- Plus 36 unit(s) shipping from 18 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £9.31 |
| 10 - 24 | £8.88 |
| 25 - 49 | £8.46 |
| 50 - 99 | £8.09 |
| 100 + | £7.75 |
*price indicative
- RS Stock No.:
- 176-7774
- Mfr. Part No.:
- 1943720000
- Brand:
- Weidmüller
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Weidmüller | |
| Product Type | Pluggable Terminal Block | |
| Number of Contacts | 16 | |
| Pitch | 5.08mm | |
| Number of Rows | 1 | |
| Current | 20A | |
| Minimum Wire Size mm² | 0.2mm² | |
| Housing Material | Copper Alloy | |
| Maximum Wire Size mm² | 4mm² | |
| Connector Gender | Female | |
| Minimum Wire Size AWG | 26AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | Right Angle | |
| Wire Connection Method | Screw | |
| Colour | Orange | |
| Voltage | 400V | |
| Series | BL | |
| Length | 92.2mm | |
| Width | 20.1mm | |
| Standards/Approvals | RoHS | |
| Depth | 16mm | |
| Select all | ||
|---|---|---|
Brand Weidmüller | ||
Product Type Pluggable Terminal Block | ||
Number of Contacts 16 | ||
Pitch 5.08mm | ||
Number of Rows 1 | ||
Current 20A | ||
Minimum Wire Size mm² 0.2mm² | ||
Housing Material Copper Alloy | ||
Maximum Wire Size mm² 4mm² | ||
Connector Gender Female | ||
Minimum Wire Size AWG 26AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation Right Angle | ||
Wire Connection Method Screw | ||
Colour Orange | ||
Voltage 400V | ||
Series BL | ||
Length 92.2mm | ||
Width 20.1mm | ||
Standards/Approvals RoHS | ||
Depth 16mm | ||
- COO (Country of Origin):
- DE
The BLZP is the functional extension of the BLZ series. The “P” in the part name stands for a Plus in security and performance in processing and use.
WIRE READY – delivered with Terminal points already opened
Power tools can be used with the globally compatible plus/minus screw head
Folded steel clamping yoke accommodates the connected wire and compensates for temperature fluctuations
The integrated wire guard prevents dangerous under insertion of the wire from occurring.
Lock and release-lever: tool-less locking and gentle releasing of the connector reduces the mechanical stress on the solder joints.
