Weidmüller BLF 5.08 Series Pluggable Terminal Block, 10-Contact, 5.08 mm Pitch, 1 Row, 1013520000

RS Stock No.:: 176-7680
Mfr. Part No.:: 1013520000
Brand:: Weidmüller

Weidmüller BLF 5.08 Series Pluggable Terminal Block, 10-Contact, 5.08 mm Pitch, 1 Row, 1013520000

Bulk discount available

Subtotal (1 box of 36 units)*

£196.02

(exc. VAT)

£235.224

(inc. VAT)

FREE delivery for orders over £50.00

Temporarily out of stock

Shipping from 21 October 2026

Need more? Click ‘Check delivery dates’ to find extra stock and lead times.

Units	Per unit	Per Box*
36 - 144	£5.445	£196.02
180 - 324	£5.102	£183.67
360 +	£4.803	£172.91

*price indicative

RS Stock No.:: 176-7680
Mfr. Part No.:: 1013520000
Brand:: Weidmüller

Specifications

Technical Reference

Legislation and Compliance

Product Details

Find similar products by selecting one or more attributes.

Select all	Attribute	Value
	Brand	Weidmüller
	Product Type	Pluggable Terminal Block
	Number of Contacts	10
	Pitch	5.08mm
	Current	10A
	Number of Rows	1
	Housing Material	Copper Tin, Polybutylene Terephthalate
	Minimum Wire Size mm²	0.2mm²
	Connector Gender	Female
	Maximum Wire Size mm²	2.5mm²
	Minimum Wire Size AWG	26 AWG
	Maximum Wire Size AWG	12 AWG
	Orientation	Straight
	Colour	Black
	Wire Connection Method	Screw
	Voltage	400 V
	Length	55.72mm
	Standards/Approvals	RoHS
	Series	BLF 5.08
	Depth	14.2mm
	Width	27.6 mm

	Select all
	Brand Weidmüller
	Product Type Pluggable Terminal Block
	Number of Contacts 10
	Pitch 5.08mm
	Current 10A
	Number of Rows 1
	Housing Material Copper Tin, Polybutylene Terephthalate
	Minimum Wire Size mm² 0.2mm²
	Connector Gender Female
	Maximum Wire Size mm² 2.5mm²
	Minimum Wire Size AWG 26 AWG
	Maximum Wire Size AWG 12 AWG
	Orientation Straight
	Colour Black
	Wire Connection Method Screw
	Voltage 400 V
	Length 55.72mm
	Standards/Approvals RoHS
	Series BLF 5.08
	Depth 14.2mm
	Width 27.6 mm

Weidmuller BLF 5.08 Series Pluggable Terminal Block, 10A Current Rating, 5.08mm Pitch - 1013520000

This pluggable Terminal Block is designed for efficient connections in a variety of electrical applications. With a Compact design and a straight body orientation, this high current Terminal Block features a 5.08mm pitch, allowing for versatile mounting via a through hole technique. The Block is composed of Durable copper alloy and PBT insulation, ensuring reliability in operation.

Features & Benefits

• Innovative PUSH IN spring connection allows for tool-free operation

• High current rating of 10A supports demanding requirements

• Touch-safe design prevents accidental contact, enhancing safety

• Robust black colour offers enhanced visibility while maintaining style

• Compatible with 26 to 12 AWG, making it adaptable to various wiring setups

Applications

• Used for mechanical and electrical assembly setups

• Suitable for requiring reliable connections in Compact spaces

• Ideal for modular systems needing quick connectivity

• Recommended for installations demanding high current capacities

What type of wire sizes can be accommodated?

This Block supports wire sizes ranging from 0.13 to 3.31 mm², suitable for both solid and flexible conductors.

How does the PUSH IN connection system improve usability?

The PUSH IN system simplifies wire connections, allowing for tool-free insertion, which saves time during installation and maintenance.

What are the temperature limits for safe operation?

The Block can operate effectively within a temperature range of -50 to 100 °C, making it suitable for a wide variety of environments.

Is this Terminal Block designed for easy reuse?

Yes, the Terminal Block is rated for up to 25 plugging cycles, ensuring reliability and longevity in various applications.
