Phoenix Contact, 7.62mm Pitch, DFK-PC 4/ 2-GF-7.62, 2 Way, , Pluggable Terminal Block, Feed Through Header, Direct
- RS Stock No.:
- 176-1434
- Mfr. Part No.:
- 1840557
- Brand:
- Phoenix Contact
Bulk discount available
Subtotal (1 unit)*
£4.11
(exc. VAT)
£4.93
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- 136 unit(s) ready to ship
- Plus 2 unit(s) ready to ship from another location
- Plus 60 unit(s) shipping from 27 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £4.11 |
| 10 - 49 | £3.67 |
| 50 - 99 | £3.42 |
| 100 - 199 | £3.15 |
| 200 + | £2.99 |
*price indicative
- RS Stock No.:
- 176-1434
- Mfr. Part No.:
- 1840557
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Pluggable Terminal Block Type | Feed Through Header | |
| Number of Contacts | 2 | |
| Pitch | 7.62mm | |
| Series | DFK-PC 4/ 2-GF-7.62 | |
| Number of Rows | 1 | |
| Body Orientation | Straight | |
| Mounting Type | Direct Mounting | |
| Termination Method | Screw | |
| Current Rating | 20A | |
| Voltage Rating | 400 V | |
| Colour | Green | |
| Material | Polyamide | |
| Contact Material | Copper Alloy | |
Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Pluggable Terminal Block Type Feed Through Header | ||
Number of Contacts 2 | ||
Pitch 7.62mm | ||
Series DFK-PC 4/ 2-GF-7.62 | ||
Number of Rows 1 | ||
Body Orientation Straight | ||
Mounting Type Direct Mounting | ||
Termination Method Screw | ||
Current Rating 20A | ||
Voltage Rating 400 V | ||
Colour Green | ||
Material Polyamide | ||
Contact Material Copper Alloy | ||
- COO (Country of Origin):
- PL
Phoenix Contact DFK-PC 4/ 2-GF-7.62 Series Pluggable Terminal Block, 7.62mm Pitch, 20A Current Rating - 1840557
This pluggable terminal block is designed for robust electrical connections in various applications. With a direct mount configuration and a compact 7.62mm pitch, this 2-contact terminal block is suitable for automating connections. Constructed from high-quality polyamide, it provides durability and reliable performance.
Features & Benefits
• Nominal current rating of 20A ensures high efficiency
• Rated voltage of 630V supports versatile applications
• Screw termination method provides secure connections
• Direct mount design simplifies installation and enhances stability
• Compliant with RoHS, ensuring environmentally friendly use
• Rated voltage of 630V supports versatile applications
• Screw termination method provides secure connections
• Direct mount design simplifies installation and enhances stability
• Compliant with RoHS, ensuring environmentally friendly use
Applications
• Used for electrical panel connections
• Suitable for industrial automation equipment
• Ideal for machinery control systems
• Utilised in telecommunications infrastructure
• Suitable for industrial automation equipment
• Ideal for machinery control systems
• Utilised in telecommunications infrastructure
Can it handle both solid and flexible cables?
Yes, it accommodates rigid and flexible conductor types.
Will it withstand high temperature environments?
Yes, operational temperature can reach up to 100°C.
