Phoenix Contact 3.81mm Pitch 2 Way Pluggable Terminal Block, Inverted Plug, Cable Mount, Screw Termination
- RS Stock No.:
- 176-1260
- Mfr. Part No.:
- 1858031
- Brand:
- Phoenix Contact
64 In stock - FREE next working day delivery available
Price Each (In a Box of 50)
£3.638
(exc. VAT)
£4.366
(inc. VAT)
Units | Per unit | Per Box* |
|---|---|---|
| 50 - 200 | £3.638 | £181.90 |
| 250 + | £3.103 | £155.15 |
*price indicative
- RS Stock No.:
- 176-1260
- Mfr. Part No.:
- 1858031
- Brand:
- Phoenix Contact
Technical Reference
Legislation and Compliance
- COO (Country of Origin):
- PL
Product Details
PCB connector, nominal current: 8 A, rated voltage (III/2): 160 V, number of positions: 2, pitch: 3.81 mm, connection method: Screw connection with tension sleeve, colour: green, contact surface: Tin
Specifications
Attribute | Value |
|---|---|
| Pluggable Terminal Block Type | Inverted Plug |
| Number of Contacts | 2 |
| Pitch | 3.81mm |
| Series | IMC 1.5/ 2-STGF-3.81 |
| Number of Rows | 1 |
| Body Orientation | Straight |
| Mounting Type | Cable Mount |
| Termination Method | Screw |
| Current Rating | 8A |
| Voltage Rating | 320 V |
| Colour | Green |
| Material | Polyamide |
