SKF GEH 30 TXG3E-2LS 30 mm Bore Plain Bearing, 375 kN, 55 mm OD
- RS Stock No.:
- 462-125
- Mfr. Part No.:
- GEH 30 TXG3E-2LS
- Brand:
- SKF
Subtotal (1 unit)*
£244.28
(exc. VAT)
£293.14
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 25 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 + | £244.28 |
*price indicative
- RS Stock No.:
- 462-125
- Mfr. Part No.:
- GEH 30 TXG3E-2LS
- Brand:
- SKF
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | SKF | |
| Product Type | Plain Bearing | |
| Bore Size | 30mm | |
| Outside Diameter | 55mm | |
| Material | Bearing Steel | |
| Static Load Rating - Axial | 375kN | |
| Series | GEH 30 TXG3E-2LS | |
| Standards/Approvals | RoHS | |
| Width | 32mm | |
| Select all | ||
|---|---|---|
Brand SKF | ||
Product Type Plain Bearing | ||
Bore Size 30mm | ||
Outside Diameter 55mm | ||
Material Bearing Steel | ||
Static Load Rating - Axial 375kN | ||
Series GEH 30 TXG3E-2LS | ||
Standards/Approvals RoHS | ||
Width 32mm | ||
- COO (Country of Origin):
- DE
Akshay
The SKF Radial spherical plain bearings are designed to accommodate radial and combined radial and axial loads, and also misalignment. This specific design includes a steel and PTFE fabric sliding contact surface combination and the bearings are maintenance-free. Except for those with designation suffix TXGR, they have a double-lip contact seal (-2RS) or a triple-lip, heavy duty contact seal (-2LS) on both sides. Those with designation suffixes TXGR, TXG3E or TXG3A are made of stainless steel.
Designed for radial and combined radial and axial loads
Long service life and maintenance-free
Suitable for very heavy, constant direction loads
Low coefficient of friction
