TDK 80dB PCB Mount High Internal Magnetic Buzzer Component, 16 (Dia.) x 7mm, 3V ac Min, 9V ac Max
- RS Stock No.:
- 134-7289
- Mfr. Part No.:
- SD160709
- Brand:
- TDK
Bulk discount available
Subtotal (1 pack of 2 units)*
£3.70
(exc. VAT)
£4.44
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 426 unit(s) shipping from 13 October 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
---|---|---|
2 - 8 | £1.85 | £3.70 |
10 - 18 | £1.48 | £2.96 |
20 - 48 | £1.295 | £2.59 |
50 - 98 | £1.13 | £2.26 |
100 + | £1.105 | £2.21 |
*price indicative
- RS Stock No.:
- 134-7289
- Mfr. Part No.:
- SD160709
- Brand:
- TDK
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | TDK | |
Mounting Type | PCB Mount | |
Minimum Supply Voltage | 3V ac | |
Maximum Supply Voltage | 9V ac | |
Sound Level | 80dB | |
Drive Type | Internal | |
Tone Type | High | |
Diameter | 16mm | |
Height | 7mm | |
Dimensions | 16 (Dia.) x 7mm | |
Minimum Operating Temperature | -10°C | |
Maximum Operating Temperature | +70°C | |
Maximum Frequency | 4.096kHz | |
Supply Current | 70mA | |
Select all | ||
---|---|---|
Brand TDK | ||
Mounting Type PCB Mount | ||
Minimum Supply Voltage 3V ac | ||
Maximum Supply Voltage 9V ac | ||
Sound Level 80dB | ||
Drive Type Internal | ||
Tone Type High | ||
Diameter 16mm | ||
Height 7mm | ||
Dimensions 16 (Dia.) x 7mm | ||
Minimum Operating Temperature -10°C | ||
Maximum Operating Temperature +70°C | ||
Maximum Frequency 4.096kHz | ||
Supply Current 70mA | ||
TDK SD Series Electromagnetic Buzzers
TDK SD series pin terminal electromagnetic buzzers are highly reliable buzzers for automobile equipment. The buzzers are compact, with a pin terminal which has a 2048Hz output. The pin terminal allows direct mounting onto printed circuit boards.
Applications
Keyboards
Clocks
Travel watches
Alarms of automobile equipment
Clocks
Travel watches
Alarms of automobile equipment
