Intelligent LED Solutions, ILH-S14645-SC201-WIR200. Si Photodiode, Surface Mount
- RS Stock No.:
- 209-7980
- Mfr. Part No.:
- ILH-S14645-SC201-WIR200.
- Brand:
- Intelligent LED Solutions
Bulk discount available
Subtotal (1 unit)*
£79.10
(exc. VAT)
£94.92
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
---|---|
1 - 4 | £79.10 |
5 - 9 | £74.67 |
10 - 24 | £71.83 |
25 - 49 | £70.01 |
50 + | £68.27 |
*price indicative
- RS Stock No.:
- 209-7980
- Mfr. Part No.:
- ILH-S14645-SC201-WIR200.
- Brand:
- Intelligent LED Solutions
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Intelligent LED Solutions | |
Wavelength of Peak Sensitivity | 840nm | |
Amplifier Function | No | |
Mounting Type | Surface Mount | |
Number of Pins | 2 | |
Diode Material | Si | |
Minimum Wavelength Detected | 400nm | |
Maximum Wavelength Detected | 1100nm | |
Length | 20mm | |
Width | 20mm | |
Height | 3.85mm | |
Peak Photo Sensitivity | 0.5A/W | |
Series | S14645 | |
Select all | ||
---|---|---|
Brand Intelligent LED Solutions | ||
Wavelength of Peak Sensitivity 840nm | ||
Amplifier Function No | ||
Mounting Type Surface Mount | ||
Number of Pins 2 | ||
Diode Material Si | ||
Minimum Wavelength Detected 400nm | ||
Maximum Wavelength Detected 1100nm | ||
Length 20mm | ||
Width 20mm | ||
Height 3.85mm | ||
Peak Photo Sensitivity 0.5A/W | ||
Series S14645 | ||
- COO (Country of Origin):
- GB
The ILD has high speed, compact Si APD for LiDAR (900nm band) featuring low-bias operation.
200mm wires
Peak sensitivity wavelength: 840nm (M=100)
Size (L x W x H): 20mm x 20mm x 3.85mm
Low bias operation: Breakdown voltage=195 V max
Peak sensitivity wavelength: 840nm (M=100)
Size (L x W x H): 20mm x 20mm x 3.85mm
Low bias operation: Breakdown voltage=195 V max
