Wurth Elektronik 127B Series PCB Terminal Strip, 2-Contact, 5mm Pitch, Through Hole Mount, 1-Row, Solder Termination
- RS Stock No.:
- 826-7251
- Mfr. Part No.:
- 691127700002B
- Brand:
- Wurth Elektronik
- RS Stock No.:
- 826-7251
- Mfr. Part No.:
- 691127700002B
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Number of Contacts | 2 | |
| Pitch | 5mm | |
| Number of Rows | 1 | |
| Mounting Type | Through Hole | |
| Gender | Female | |
| Termination Method | Solder | |
| Type | PCB Terminal Block | |
| Current Rating | 20A | |
| Body Orientation | Straight | |
| Colour | Green | |
| Voltage Rating | 300 V ac | |
| Series | 127B | |
| Depth | 19.5mm | |
| Length | 18.6mm | |
| Material | Polyamide, Steel | |
| Width | 12.5mm | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Number of Contacts 2 | ||
Pitch 5mm | ||
Number of Rows 1 | ||
Mounting Type Through Hole | ||
Gender Female | ||
Termination Method Solder | ||
Type PCB Terminal Block | ||
Current Rating 20A | ||
Body Orientation Straight | ||
Colour Green | ||
Voltage Rating 300 V ac | ||
Series 127B | ||
Depth 19.5mm | ||
Length 18.6mm | ||
Material Polyamide, Steel | ||
Width 12.5mm | ||
Wurth WR-TBL 127 B Series 5mm Vertical Entry Modular Terminal Block Connectors with Stamping Clamp
WR-TBL 127 B series 5mm pitch PCB terminal block connectors with a vertical wire entry and stamping clamp. These 127 B series 5mm PCB terminal blocks use a 'slot' type M2.6 screw terminal which accepts a wire size of AWG 30-12 and have a stainless steel wire guard. The body of these 5mm WR-TBL modular terminal blocks is made from green UL94-V0 PA66 and the contacts are tin plated.
Wurth Elektronik WR-TBL are available in different connection types and offer large and modular terminal block possibilities in order to fulfil most of the requirements which can be found in the industrial marketplace.
Wurth 5.0mm Pitch Terminal Blocks
