Phoenix Contact MKDSN 2.5/3 BD:1-3 Series PCB Terminal Block, 3-Contact, 5mm Pitch, Through Hole Mount, 1-Row, Screw
- RS Stock No.:
- 802-4723
- Mfr. Part No.:
- 1734669
- Brand:
- Phoenix Contact
Currently unavailable
Sorry, we don't know when this will be back in stock.
- RS Stock No.:
- 802-4723
- Mfr. Part No.:
- 1734669
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 3 | |
| Pitch | 5mm | |
| Number of Rows | 1 | |
| Mounting Type | Through Hole | |
| Gender | Male | |
| Termination Method | Screw | |
| Type | PCB Terminal Block | |
| Current Rating | 16A | |
| Body Orientation | Straight | |
| Colour | Green | |
| Voltage Rating | 400 V | |
| Series | MKDSN 2.5/3 BD:1-3 | |
| Length | 18.5mm | |
| Material | Polyamide | |
| Depth | 9.5mm | |
| Width | 15mm | |
Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 3 | ||
Pitch 5mm | ||
Number of Rows 1 | ||
Mounting Type Through Hole | ||
Gender Male | ||
Termination Method Screw | ||
Type PCB Terminal Block | ||
Current Rating 16A | ||
Body Orientation Straight | ||
Colour Green | ||
Voltage Rating 400 V | ||
Series MKDSN 2.5/3 BD:1-3 | ||
Length 18.5mm | ||
Material Polyamide | ||
Depth 9.5mm | ||
Width 15mm | ||
Phoenix Contact PCB Terminal Block, Through-Hole Mounting, 400 V Voltage Rating - 1734669
This PCB terminal block by Phoenix Contact is a high-quality, green-coloured, straight orientation terminal block suitable for a wide range of applications. With a current rating of 16A and a voltage rating of 400V, this terminal block is reliable and efficient.
Features & Benefits
• This component features a straight body orientation, ensuring precise alignment in the assembly
• It is specifically designed with a male gender specification to fit seamlessly into compatible connectors
• Utilising a through hole mounting type, it offers secure and stable attachment on circuit boards
• The screw termination method employed allows for reliable and adjustable connections
• It has a robust 400V voltage rating, ensuring safe operation under typical electrical conditions
• It is specifically designed with a male gender specification to fit seamlessly into compatible connectors
• Utilising a through hole mounting type, it offers secure and stable attachment on circuit boards
• The screw termination method employed allows for reliable and adjustable connections
• It has a robust 400V voltage rating, ensuring safe operation under typical electrical conditions
Applications
• Ideal for use in PCB assemblies
• Suitable for industrial automation • Can be used for electrical equipment installations
• Suitable for industrial automation • Can be used for electrical equipment installations
Can it be used for industrial automation applications?
Yes, this PCB terminal block is reliable for industrial automation applications.
Will it fit standard PCB layouts?
Yes, the 5mm pitch and 10mm width make it suitable for standard PCB layouts.
Is it suitable for high voltage applications?
Yes, with a voltage rating of 400V, it is suitable for high voltage applications.
Phoenix Contact COMBICON 5.0mm PCB Terminal Blocks
