Phoenix Contact PTA Series PCB Terminal Block, 6-Contact, 5 mm Pitch, PCB, 1 Row
- RS Stock No.:
- 284-0639
- Mfr. Part No.:
- 1988846
- Brand:
- Phoenix Contact
Subtotal (1 pack of 100 units)*
£159.20
(exc. VAT)
£191.00
(inc. VAT)
FREE delivery for orders over £60.00
Stocked by manufacturer
- Ready to ship from 17 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 100 + | £1.592 | £159.20 |
*price indicative
- RS Stock No.:
- 284-0639
- Mfr. Part No.:
- 1988846
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 6 | |
| Product Type | PCB Terminal Block | |
| Pitch | 5mm | |
| Number of Rows | 1 | |
| Current | 17.5A | |
| Mount Type | PCB | |
| Minimum Wire Size mm² | 0.14mm² | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 14AWG | |
| Maximum Wire Size AWG | 26AWG | |
| Colour | Green | |
| Wire Connection Method | Screw | |
| Voltage | 40V | |
| Standards/Approvals | cULus VDE China RoHS, RoHS, WEEE | |
| Depth | 15.4mm | |
| Series | PTA | |
| Length | 12.8mm | |
| Width | 3mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 6 | ||
Product Type PCB Terminal Block | ||
Pitch 5mm | ||
Number of Rows 1 | ||
Current 17.5A | ||
Mount Type PCB | ||
Minimum Wire Size mm² 0.14mm² | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 14AWG | ||
Maximum Wire Size AWG 26AWG | ||
Colour Green | ||
Wire Connection Method Screw | ||
Voltage 40V | ||
Standards/Approvals cULus VDE China RoHS, RoHS, WEEE | ||
Depth 15.4mm | ||
Series PTA | ||
Length 12.8mm | ||
Width 3mm | ||
- COO (Country of Origin):
- IN
The Phoenix Contact PCB terminal block employs a well known connection principle, enabling its versatile use worldwide. Its design prioritizes performance with low temperature rise, achieved through maximum contact force. An angled connection enables multi row arrangement on the PCB. The latching on the side enables various numbers of positions to be combined.
High terminal block capacity
Rectangular terminal block space
Allows connection of two conductors
