Same Sky TB003-500 Series PCB Terminal Block, 2-Contact, 5 mm Pitch
- RS Stock No.:
- 259-6739
- Mfr. Part No.:
- TB003-500-P02BE
- Brand:
- Same Sky
Subtotal (1 bag of 3000 units)*
£321.00
(exc. VAT)
£384.00
(inc. VAT)
Stock information currently inaccessible - Please check back later
Units | Per unit | Per Bag* |
|---|---|---|
| 3000 + | £0.107 | £321.00 |
*price indicative
- RS Stock No.:
- 259-6739
- Mfr. Part No.:
- TB003-500-P02BE
- Brand:
- Same Sky
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Same Sky | |
| Number of Contacts | 2 | |
| Product Type | PCB Terminal Block | |
| Pitch | 5mm | |
| Current | 10A | |
| Housing Material | Polyamide 66 | |
| Connector Gender | Male | |
| Minimum Wire Size AWG | 26AWG | |
| Maximum Wire Size AWG | 14AWG | |
| Orientation | Horizontal | |
| Colour | Blue | |
| Wire Connection Method | Screw | |
| Voltage | 300V | |
| Standards/Approvals | UL 1059, RoHS, EN 60998-2-1:2004, EN 60998-1:2004, CE | |
| Series | TB003-500 | |
| Depth | 10.3mm | |
| Length | 10mm | |
| Width | 7.8mm | |
| Select all | ||
|---|---|---|
Brand Same Sky | ||
Number of Contacts 2 | ||
Product Type PCB Terminal Block | ||
Pitch 5mm | ||
Current 10A | ||
Housing Material Polyamide 66 | ||
Connector Gender Male | ||
Minimum Wire Size AWG 26AWG | ||
Maximum Wire Size AWG 14AWG | ||
Orientation Horizontal | ||
Colour Blue | ||
Wire Connection Method Screw | ||
Voltage 300V | ||
Standards/Approvals UL 1059, RoHS, EN 60998-2-1:2004, EN 60998-1:2004, CE | ||
Series TB003-500 | ||
Depth 10.3mm | ||
Length 10mm | ||
Width 7.8mm | ||
The CUI devices provides a PCB terminal blocks having a pitch of 5 mm with a rated voltage of 300 V having a philips head screw. It consist of a horizontal body orientation and the number of poles are 2.
Operating temperature of -40°C to 105°C
Contact resistance is 20 mΩ
