Weidmüller OMNIMATE Signal Series PCB Terminal Block, 2-Contact, 10 mm Pitch, PCB, 1 Row
- RS Stock No.:
- 255-8275
- Mfr. Part No.:
- 1953470000
- Brand:
- Weidmüller
Subtotal (1 box of 100 units)*
£45.58
(exc. VAT)
£54.70
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 20 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £45.58 | £0.456 |
*price indicative
- RS Stock No.:
- 255-8275
- Mfr. Part No.:
- 1953470000
- Brand:
- Weidmüller
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Weidmüller | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 2 | |
| Pitch | 10mm | |
| Number of Rows | 1 | |
| Current | 24A | |
| Mount Type | PCB | |
| Housing Material | Polyamide | |
| Minimum Wire Size mm² | 0.13mm² | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 26AWG | |
| Maximum Wire Size AWG | 14AWG | |
| Orientation | 135° | |
| Wire Connection Method | Clamp | |
| Colour | Orange | |
| Voltage | 1000V | |
| Depth | 14.5mm | |
| Series | OMNIMATE Signal | |
| Standards/Approvals | Ex e II (KEMA07 ATAEX0047U), ATEX certification Ex II 2GD | |
| Width | 22.5mm | |
| Length | 16.48mm | |
| Select all | ||
|---|---|---|
Brand Weidmüller | ||
Product Type PCB Terminal Block | ||
Number of Contacts 2 | ||
Pitch 10mm | ||
Number of Rows 1 | ||
Current 24A | ||
Mount Type PCB | ||
Housing Material Polyamide | ||
Minimum Wire Size mm² 0.13mm² | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 26AWG | ||
Maximum Wire Size AWG 14AWG | ||
Orientation 135° | ||
Wire Connection Method Clamp | ||
Colour Orange | ||
Voltage 1000V | ||
Depth 14.5mm | ||
Series OMNIMATE Signal | ||
Standards/Approvals Ex e II (KEMA07 ATAEX0047U), ATEX certification Ex II 2GD | ||
Width 22.5mm | ||
Length 16.48mm | ||
- COO (Country of Origin):
- CN
The Weidmuller compact installation terminal for the standard wire cross-section size of 2.5mm², tension clamp connection with a 135° outlet direction.
Safe
Long-term temperature resistant
Adaptable
Convenient
