WAGO PCB Terminal Block, 4-Contact, 7.5 mm Pitch, 1 Row, 2626-3104/020-000
- RS Stock No.:
- 240-7832
- Distrelec Article No.:
- 304-33-179
- Mfr. Part No.:
- 2626-3104/020-000
- Brand:
- WAGO
Subtotal (1 pack of 70 units)*
£316.75
(exc. VAT)
£380.10
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 24 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Pack* |
|---|---|---|
| 70 + | £4.525 | £316.75 |
*price indicative
- RS Stock No.:
- 240-7832
- Distrelec Article No.:
- 304-33-179
- Mfr. Part No.:
- 2626-3104/020-000
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 4 | |
| Product Type | PCB Terminal Block | |
| Pitch | 7.5mm | |
| Current | 38A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 10mm² | |
| Connector Gender | Female | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 8AWG | |
| Orientation | Straight | |
| Colour | Grey | |
| Wire Connection Method | Push-in | |
| Voltage | 600V | |
| Standards/Approvals | UL, CSA | |
| Width | 31.8mm | |
| Depth | 18.5mm | |
| Length | 28.2mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 4 | ||
Product Type PCB Terminal Block | ||
Pitch 7.5mm | ||
Current 38A | ||
Number of Rows 1 | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 10mm² | ||
Connector Gender Female | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 8AWG | ||
Orientation Straight | ||
Colour Grey | ||
Wire Connection Method Push-in | ||
Voltage 600V | ||
Standards/Approvals UL, CSA | ||
Width 31.8mm | ||
Depth 18.5mm | ||
Length 28.2mm | ||
The WAGO PCB terminal block has 4 pole and push-in cage clamp connection. It has 90° conductor connection direction to PCB. It provides push-in termination of solid and ferruled conductors.
Ideal for panel feedthrough applications
6 mm² conductor connection size
