Weidmüller LL Series PCB Terminal Block, 5-Contact, 6.35 mm Pitch, PCB, 1 Row Solder
- RS Stock No.:
- 214-4522
- Mfr. Part No.:
- 1356870000
- Brand:
- Weidmüller
Bulk discount available
View bulk pricing optionsSubtotal (1 unit)*
£2.80
(exc. VAT)
£3.36
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 28 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit |
|---|---|
| 1 - 9 | £2.80 |
| 10 - 19 | £2.60 |
| 20 + | £2.40 |
*price indicative
- RS Stock No.:
- 214-4522
- Mfr. Part No.:
- 1356870000
- Brand:
- Weidmüller
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Weidmüller | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 5 | |
| Pitch | 6.35mm | |
| Number of Rows | 1 | |
| Current | 32A | |
| Housing Material | Polyamide | |
| Mount Type | PCB | |
| Connector Gender | Female | |
| Orientation | Right Angle | |
| Termination Type | Solder | |
| Colour | Black | |
| Contact Gender | Female | |
| Voltage | 1000V | |
| Series | LL | |
| Width | 32.35mm | |
| Standards/Approvals | RoHS | |
| Depth | 15.85mm | |
| Length | 33.5mm | |
| Select all | ||
|---|---|---|
Brand Weidmüller | ||
Product Type PCB Terminal Block | ||
Number of Contacts 5 | ||
Pitch 6.35mm | ||
Number of Rows 1 | ||
Current 32A | ||
Housing Material Polyamide | ||
Mount Type PCB | ||
Connector Gender Female | ||
Orientation Right Angle | ||
Termination Type Solder | ||
Colour Black | ||
Contact Gender Female | ||
Voltage 1000V | ||
Series LL | ||
Width 32.35mm | ||
Standards/Approvals RoHS | ||
Depth 15.85mm | ||
Length 33.5mm | ||
- COO (Country of Origin):
- CN
The Weidmuller PCB Connector has pitch 6.35 mm, with proven clamping yoke connection provides the following features: connections for 1000 V, 32 A, 6 mm² conductor cross-section, and off-set solder pins, 90° conductor outlet direction.
Mounting onto the PCB THT solder connection
Pitch in mm (P) 6.35 mm
Number of poles 2
Max. adjacent poles per row 24
