Wurth Elektronik 2431 Series PCB Terminal Block, 10-Contact, 3.5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 190-8786
- Mfr. Part No.:
- 691243100010
- Brand:
- Wurth Elektronik
Subtotal (1 bag of 200 units)*
£860.00
(exc. VAT)
£1,032.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 28 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Bag* |
|---|---|---|
| 200 + | £4.30 | £860.00 |
*price indicative
- RS Stock No.:
- 190-8786
- Mfr. Part No.:
- 691243100010
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 10 | |
| Pitch | 3.5mm | |
| Current | 10A | |
| Number of Rows | 1 | |
| Mount Type | Through Hole | |
| Minimum Wire Size mm² | 0.05mm² | |
| Maximum Wire Size mm² | 1.31mm² | |
| Orientation | Vertical | |
| Colour | Green | |
| Series | 2431 | |
| Depth | 9.1mm | |
| Length | 35mm | |
| Standards/Approvals | cULus, RoHS, VDE | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type PCB Terminal Block | ||
Number of Contacts 10 | ||
Pitch 3.5mm | ||
Current 10A | ||
Number of Rows 1 | ||
Mount Type Through Hole | ||
Minimum Wire Size mm² 0.05mm² | ||
Maximum Wire Size mm² 1.31mm² | ||
Orientation Vertical | ||
Colour Green | ||
Series 2431 | ||
Depth 9.1mm | ||
Length 35mm | ||
Standards/Approvals cULus, RoHS, VDE | ||
WR-TBL Würth Elektronik Teminal Blocks
The terminal block portfolio from Würth Elektronik gives piece of mind bringing power to the board. The newly stocked range covers wire protector, rising cage clamp, spring clamp and pluggable systems. From 2.50 mm up to 10.16 mm pitch, 57 Amp and a maximum number of up to 12 poles.
