Phoenix Contact PTSM Series PCB Terminal Block, 8-Contact, 2.5 mm Pitch, Solder, 1 Row
- RS Stock No.:
- 638-327
- Mfr. Part No.:
- 1814692
- Brand:
- Phoenix Contact
Subtotal (1 pack of 770 units)*
£2,152.88
(exc. VAT)
£2,583.46
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 21 September 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £2,152.88 | £2.796 |
*price indicative
- RS Stock No.:
- 638-327
- Mfr. Part No.:
- 1814692
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Number of Contacts | 8 | |
| Product Type | PCB Terminal Block | |
| Pitch | 2.5mm | |
| Current | 6A | |
| Number of Rows | 1 | |
| Mount Type | Solder | |
| Housing Material | Polyamide Fibreglass | |
| Minimum Wire Size mm² | 0.14mm² | |
| Maximum Wire Size mm² | 0.5mm² | |
| Minimum Wire Size AWG | 26AWG | |
| Maximum Wire Size AWG | 20AWG | |
| Orientation | 0° | |
| Colour | Signal White | |
| Wire Connection Method | Push-in | |
| Voltage | 160V | |
| Width | 24.4mm | |
| Standards/Approvals | cULus Recognised, IEC 60664-1:2007-04, IEC 60998-1:2002-12, IEC 60998-2-1:2002-12, IEC 60998-2-2:2002-12, UL Recognised, VDE | |
| Length | 11mm | |
| Series | PTSM | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 8 | ||
Product Type PCB Terminal Block | ||
Pitch 2.5mm | ||
Current 6A | ||
Number of Rows 1 | ||
Mount Type Solder | ||
Housing Material Polyamide Fibreglass | ||
Minimum Wire Size mm² 0.14mm² | ||
Maximum Wire Size mm² 0.5mm² | ||
Minimum Wire Size AWG 26AWG | ||
Maximum Wire Size AWG 20AWG | ||
Orientation 0° | ||
Colour Signal White | ||
Wire Connection Method Push-in | ||
Voltage 160V | ||
Width 24.4mm | ||
Standards/Approvals cULus Recognised, IEC 60664-1:2007-04, IEC 60998-1:2002-12, IEC 60998-2-1:2002-12, IEC 60998-2-2:2002-12, UL Recognised, VDE | ||
Length 11mm | ||
Series PTSM | ||
- COO (Country of Origin):
- IN
The Phoenix Contact PCB terminal block is designed to deliver reliable connections within compact circuitry. With its thoughtful push-in spring connection method, the product ensures a stable and quick assembly without the need for additional tools, making installation straightforward for professionals. Engineered for SMD soldering, this model's dimensions and pin layout optimise space efficiency, while its robust current handling capabilities reflect its suitability for high-performance applications. The striking signal white colour not only adds to its aesthetic appeal but also enhances visibility during assembly.
Constructed from materials that comply with WEEE/RoHS directives
Engineered for superior energy efficiency and high performance in demanding applications
Equipped with additional solder anchors to reduce mechanical strain on connections
Designed for integration into SMT processes, facilitating high speed production
