Phoenix Contact SPT Series PCB Terminal Block, 5-Contact, 5.08mm Pitch, Surface Mount, 1-Row, Push In Spring Termination
- RS Stock No.:
- 557-636
- Mfr. Part No.:
- 1824885
- Brand:
- Phoenix Contact
Subtotal (1 pack of 300 units)*
£498.87
(exc. VAT)
£598.64
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 999,999,999 unit(s) shipping from 29 December 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £498.87 | £1.663 |
*price indicative
- RS Stock No.:
- 557-636
- Mfr. Part No.:
- 1824885
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Number of Contacts | 5 | |
Pitch | 5.08mm | |
Number of Rows | 1 | |
Mounting Type | Surface Mount | |
Termination Method | Push In Spring | |
Series | SPT | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Number of Contacts 5 | ||
Pitch 5.08mm | ||
Number of Rows 1 | ||
Mounting Type Surface Mount | ||
Termination Method Push In Spring | ||
Series SPT | ||
- COO (Country of Origin):
- PL
The Phoenix Contact printed circuit board terminal block engineered to deliver reliability and efficiency in various electronic applications. With a robust push-in spring connection method, it simplifies installation while ensuring a secure and durable connection. This terminal block supports a nominal current of 17.5 A and a rated voltage of 320 V, making it suitable for a wide range of electrical tasks. Its compact design, characterised by a pitch of 5.08 mm and a linear pin layout, allows for optimal space utilisation on PCBs. The device is designed for SMD soldering, ensuring easy integration into automated assembly processes, making it a practical choice for modern manufacturing environments.
Time-saving push-in connection eliminates the need for tools
Colour-coded actuating push button enhances user-friendly operation
Integrated test option allows for quick and convenient testing
Mechanical strain reduction is achieved with solder anchors on outer poles
Optimised for SMT soldering processes ensures seamless integration into production
Material compliance with WEEE and RoHS standards guarantees environmental safety
Tested for mechanical and electrical reliability to meet stringent industry standards
Compact dimensions facilitate efficient use of board space
Colour-coded actuating push button enhances user-friendly operation
Integrated test option allows for quick and convenient testing
Mechanical strain reduction is achieved with solder anchors on outer poles
Optimised for SMT soldering processes ensures seamless integration into production
Material compliance with WEEE and RoHS standards guarantees environmental safety
Tested for mechanical and electrical reliability to meet stringent industry standards
Compact dimensions facilitate efficient use of board space
