Phoenix Contact LPT Series PCB Terminal Block, 9-Contact, 7.5 mm Pitch, Wave Soldering Mount, 1 Row
- RS Stock No.:
- 556-921
- Mfr. Part No.:
- 1438132
- Brand:
- Phoenix Contact
Subtotal (1 pack of 25 units)*
£246.43
(exc. VAT)
£295.72
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 03 August 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
|---|---|---|
| 1 + | £246.43 | £9.857 |
*price indicative
- RS Stock No.:
- 556-921
- Mfr. Part No.:
- 1438132
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Phoenix Contact | |
| Product Type | PCB Terminal Block | |
| Number of Contacts | 9 | |
| Pitch | 7.5mm | |
| Current | 41A | |
| Number of Rows | 1 | |
| Mount Type | Wave Soldering Mount | |
| Minimum Wire Size mm² | 0.2mm² | |
| Housing Material | Polyamide | |
| Maximum Wire Size mm² | 1mm² | |
| Minimum Wire Size AWG | 22AWG | |
| Maximum Wire Size AWG | 8AWG | |
| Orientation | 0° | |
| Wire Connection Method | Push-in | |
| Colour | Green | |
| Voltage | 1000V | |
| Standards/Approvals | cULus Recognised, UL Recognised, VDE | |
| Series | LPT | |
| Length | 24.3mm | |
| Width | 68.5mm | |
| Select all | ||
|---|---|---|
Brand Phoenix Contact | ||
Product Type PCB Terminal Block | ||
Number of Contacts 9 | ||
Pitch 7.5mm | ||
Current 41A | ||
Number of Rows 1 | ||
Mount Type Wave Soldering Mount | ||
Minimum Wire Size mm² 0.2mm² | ||
Housing Material Polyamide | ||
Maximum Wire Size mm² 1mm² | ||
Minimum Wire Size AWG 22AWG | ||
Maximum Wire Size AWG 8AWG | ||
Orientation 0° | ||
Wire Connection Method Push-in | ||
Colour Green | ||
Voltage 1000V | ||
Standards/Approvals cULus Recognised, UL Recognised, VDE | ||
Series LPT | ||
Length 24.3mm | ||
Width 68.5mm | ||
- COO (Country of Origin):
- CN
The Phoenix Contact PCB terminal block is engineered to deliver high performance in demanding applications. Recognised for its robust design, it ensures dependable connections with a nominal current rating of 41 A and a rated voltage up to 1000 V. The product features a unique lever push-in connection method that allows for tool-free installation, significantly reducing assembly time. Its compact dimensions and green colour aid in streamlined PCB designs, while the zigzag pinning layout enhances stability within circuits.
WEEE/RoHS compliant materials promote environmental sustainability
Robust construction ensures long term reliability under diverse conditions
Wide range of compatible conductor sizes enhances application versatility
Wave soldering mounting type allows for efficient PCB integration
