WAGO 2604 Series PCB Connector, 10-Contact, 5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 225-453
- Mfr. Part No.:
- 2604-1110
- Brand:
- WAGO
Subtotal (1 box of 40 units)*
£272.30
(exc. VAT)
£326.76
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 28 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £272.30 | £6.808 |
*price indicative
- RS Stock No.:
- 225-453
- Mfr. Part No.:
- 2604-1110
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 10 | |
| Product Type | PCB Connector | |
| Pitch | 5mm | |
| Number of Rows | 1 | |
| Current | 32A | |
| Mount Type | Through Hole | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | 0° | |
| Colour | Grey | |
| Voltage | 32V | |
| Standards/Approvals | No | |
| Depth | 19.2mm | |
| Width | 52.4mm | |
| Series | 2604 | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 10 | ||
Product Type PCB Connector | ||
Pitch 5mm | ||
Number of Rows 1 | ||
Current 32A | ||
Mount Type Through Hole | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation 0° | ||
Colour Grey | ||
Voltage 32V | ||
Standards/Approvals No | ||
Depth 19.2mm | ||
Width 52.4mm | ||
Series 2604 | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block offers a robust connection solution tailored for both convenience and performance. Designed with a user-friendly push-in CAGE CLAMP mechanism, it accommodates a range of conductor sizes, making installation quick and effortless. The intuitive lever actuation allows for simultaneous handling of multiple clamping units, streamlining the process for multi-core cable connections.
Compatible with a wide range of conductor sizes enhancing versatility
Complies with IEC and UL standards ensuring safety and reliability
Lightweight design optimises space without compromising on performance
Test specifications confirm reliability under environmental stress conditions
