WAGO 2604 Series PCB Connector, 8-Contact, 7.5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 225-110
- Mfr. Part No.:
- 2604-3308
- Brand:
- WAGO
Subtotal (1 box of 30 units)*
£179.68
(exc. VAT)
£215.62
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 09 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £179.68 | £5.989 |
*price indicative
- RS Stock No.:
- 225-110
- Mfr. Part No.:
- 2604-3308
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 8 | |
| Pitch | 7.5mm | |
| Current | 32A | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.2mm² | |
| Housing Material | Polyamide 66 | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | 90° | |
| Colour | Grey | |
| Wire Connection Method | Push-in | |
| Voltage | 63V | |
| Width | 59.9mm | |
| Series | 2604 | |
| Depth | 16.7mm | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 8 | ||
Pitch 7.5mm | ||
Current 32A | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.2mm² | ||
Housing Material Polyamide 66 | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation 90° | ||
Colour Grey | ||
Wire Connection Method Push-in | ||
Voltage 63V | ||
Width 59.9mm | ||
Series 2604 | ||
Depth 16.7mm | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- PL
The Wago Terminal block features a push-in CAGE CLAMP connection system, specifically designed for maximum efficiency and ease of use. Tailored for printed circuit boards, this terminal block provides an innovative lever actuation method, ensuring tool-free operation and facilitating rapid installations. With a robust build and a grey finish, it is suitable for various applications while guaranteeing reliability.
Establishes secure connections for a variety of conductor sizes
Constructed from high quality materials ensuring durability and longevity
Optimised for PCB applications allowing for straightforward integration
Aligned with stringent international electrical standards for safety
