WAGO 254 Series PCB Connector, 4-Contact, 5.08 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 224-945
- Mfr. Part No.:
- 254-454
- Brand:
- WAGO
Subtotal (1 box of 55 units)*
£51.66
(exc. VAT)
£61.99
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 21 April 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £51.66 | £0.939 |
*price indicative
- RS Stock No.:
- 224-945
- Mfr. Part No.:
- 254-454
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 4 | |
| Product Type | PCB Connector | |
| Pitch | 5.08mm | |
| Number of Rows | 1 | |
| Current | 24A | |
| Mount Type | Through Hole | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.5mm² | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 20 AWG | |
| Maximum Wire Size AWG | 12 AWG | |
| Orientation | 45° | |
| Colour | Grey | |
| Wire Connection Method | Push Wire | |
| Voltage | 32 V | |
| Standards/Approvals | No | |
| Width | 21.5 mm | |
| Series | 254 | |
| Depth | 13.5mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 4 | ||
Product Type PCB Connector | ||
Pitch 5.08mm | ||
Number of Rows 1 | ||
Current 24A | ||
Mount Type Through Hole | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.5mm² | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 20 AWG | ||
Maximum Wire Size AWG 12 AWG | ||
Orientation 45° | ||
Colour Grey | ||
Wire Connection Method Push Wire | ||
Voltage 32 V | ||
Standards/Approvals No | ||
Width 21.5 mm | ||
Series 254 | ||
Depth 13.5mm | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block combines functionality and efficiency, designed for seamless integration into your electronic projects. Engineered with PUSH WIRE technology, the product enables hassle-free termination of both solid and ferruled conductors. With a compact depth of just 8.9 mm, it optimises space on your printed circuit board, all while maintaining robust electrical performance.
Accommodates multiple pole configurations for versatile applications
Constructed with high quality materials for enhanced durability
Compliant with industry standards for safety and performance
Ideal for marine and other critical environments
