WAGO 739 Series PCB Connector, 9-Contact, 3.5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 224-585
- Mfr. Part No.:
- 739-309
- Brand:
- WAGO
Subtotal (1 box of 35 units)*
£119.84
(exc. VAT)
£143.81
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 17 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £119.84 | £3.424 |
*price indicative
- RS Stock No.:
- 224-585
- Mfr. Part No.:
- 739-309
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 9 | |
| Pitch | 3.5mm | |
| Number of Rows | 1 | |
| Current | 17.5A | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 2mm² | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 1.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 14AWG | |
| Orientation | Vertical | |
| Wire Connection Method | Cage Clamp | |
| Colour | Grey | |
| Voltage | 160V | |
| Standards/Approvals | No | |
| Width | 33mm | |
| Series | 739 | |
| Depth | 13.4mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 9 | ||
Pitch 3.5mm | ||
Number of Rows 1 | ||
Current 17.5A | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 2mm² | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 1.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 14AWG | ||
Orientation Vertical | ||
Wire Connection Method Cage Clamp | ||
Colour Grey | ||
Voltage 160V | ||
Standards/Approvals No | ||
Width 33mm | ||
Series 739 | ||
Depth 13.4mm | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block is an exemplary solution for efficient and reliable connections in electronic circuits. Designed to accommodate a wide range of conductor sizes, this terminal block ensures a secure and adaptable connection for various applications. With its compact dimensions and intelligent design, it facilitates space-saving installations while maintaining superior functionality and performance.
Provides an extensive limit temperature range making it suitable for various conditions
Compatible with an array of ferrules for enhanced adaptability
Streamlined installation process thanks to screwdriver actuated connection
Complies with multiple international standards for assurance in diverse markets
