WAGO 739 Series PCB Connector, 4-Contact, 5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 223-520
- Mfr. Part No.:
- 739-104
- Brand:
- WAGO
Subtotal (1 box of 55 units)*
£87.21
(exc. VAT)
£104.65
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £87.21 | £1.586 |
*price indicative
- RS Stock No.:
- 223-520
- Mfr. Part No.:
- 739-104
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 4 | |
| Pitch | 5mm | |
| Current | 24A | |
| Number of Rows | 1 | |
| Mount Type | Through Hole | |
| Minimum Wire Size mm² | 0.08mm² | |
| Housing Material | Polyamide 66 | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | Vertical | |
| Wire Connection Method | Cage Clamp | |
| Colour | Grey | |
| Voltage | 32V | |
| Series | 739 | |
| Width | 21.5mm | |
| Standards/Approvals | No | |
| Depth | 14.3mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 4 | ||
Pitch 5mm | ||
Current 24A | ||
Number of Rows 1 | ||
Mount Type Through Hole | ||
Minimum Wire Size mm² 0.08mm² | ||
Housing Material Polyamide 66 | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation Vertical | ||
Wire Connection Method Cage Clamp | ||
Colour Grey | ||
Voltage 32V | ||
Series 739 | ||
Width 21.5mm | ||
Standards/Approvals No | ||
Depth 14.3mm | ||
- COO (Country of Origin):
- CH
The Wago PCB terminal block offers a secure, reliable connection with a sophisticated CAGE CLAMP technology. Designed for ease of installation and optimal space utilisation, this component is perfect for various applications requiring robust performance and safety. Supporting a range of conductor cross-sections, it ensures seamless integration into your circuit design while adhering to stringent electrical standards.
Provides excellent electrical performance with minimal risk of surges
Lightweight design facilitates easier handling and assembly
Fully RoHS compliant supporting environmentally friendly practices
