WAGO 745 Series PCB Connector, 2-Contact, 7.5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 223-178
- Mfr. Part No.:
- 745-3152
- Brand:
- WAGO
Subtotal (1 box of 228 units)*
£338.51
(exc. VAT)
£406.21
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 12 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £338.51 | £1.485 |
*price indicative
- RS Stock No.:
- 223-178
- Mfr. Part No.:
- 745-3152
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 2 | |
| Product Type | PCB Connector | |
| Pitch | 7.5mm | |
| Number of Rows | 1 | |
| Minimum Wire Size mm² | 0.08mm² | |
| Housing Material | Polyamide 66 | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | 45° | |
| Wire Connection Method | Cage Clamp | |
| Colour | Grey | |
| Length | 6.5mm | |
| Width | 14mm | |
| Depth | 19.4mm | |
| Standards/Approvals | No | |
| Series | 745 | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 2 | ||
Product Type PCB Connector | ||
Pitch 7.5mm | ||
Number of Rows 1 | ||
Minimum Wire Size mm² 0.08mm² | ||
Housing Material Polyamide 66 | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation 45° | ||
Wire Connection Method Cage Clamp | ||
Colour Grey | ||
Length 6.5mm | ||
Width 14mm | ||
Depth 19.4mm | ||
Standards/Approvals No | ||
Series 745 | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block, designed for superior connectivity, excels in environments demanding reliability and performance. Engineered with a CAGE CLAMP connection technology, it ensures a secure grip for various conductor types, making it ideal for compact electronic designs. The thoughtfully orchestrated dimensions and pin spacing allow for flexible placement in your PCB layout, facilitating optimal use of space.
Manufactured from high quality materials for long lasting performance
Designed to support both solid and fine stranded conductors
Exceeds stringent environmental compliance for increased reliability
Available in multiple variants to suit diverse application needs
