WAGO 745 Series PCB Connector, 2-Contact, 10 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 222-781
- Mfr. Part No.:
- 745-202
- Brand:
- WAGO
Subtotal (1 box of 160 units)*
£245.63
(exc. VAT)
£294.76
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 16 November 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £245.63 | £1.535 |
*price indicative
- RS Stock No.:
- 222-781
- Mfr. Part No.:
- 745-202
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 2 | |
| Product Type | PCB Connector | |
| Pitch | 10mm | |
| Current | 32A | |
| Number of Rows | 1 | |
| Mount Type | Through Hole | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.08mm² | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Colour | Grey | |
| Wire Connection Method | Cage Clamp | |
| Voltage | 63V | |
| Depth | 22.9mm | |
| Series | 745 | |
| Width | 16.5mm | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 2 | ||
Product Type PCB Connector | ||
Pitch 10mm | ||
Current 32A | ||
Number of Rows 1 | ||
Mount Type Through Hole | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.08mm² | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Colour Grey | ||
Wire Connection Method Cage Clamp | ||
Voltage 63V | ||
Depth 22.9mm | ||
Series 745 | ||
Width 16.5mm | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block is designed for seamless integration into modern electronic applications. With a robust CAGE CLAMP connection technology, it accommodates a variety of conductor sizes, ensuring flexibility and reliability in connections. The compact dimensions and conveniently positioned solder pins provide high mechanical stability, making it an ideal choice for crowded circuit boards.
Compliant with RoHS standards underscoring environmental responsibility
Offers various connection options including solid and fine stranded conductors
Integrates commoning capabilities for streamlined potential distribution
Constructed from V0 flame retardant materials providing safety in critical applications
