WAGO 745 Series PCB Connector, 2-Contact, 10 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 222-478
- Mfr. Part No.:
- 745-1352
- Brand:
- WAGO
Subtotal (1 box of 104 units)*
£217.43
(exc. VAT)
£260.92
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 15 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £217.43 | £2.091 |
*price indicative
- RS Stock No.:
- 222-478
- Mfr. Part No.:
- 745-1352
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 2 | |
| Product Type | PCB Connector | |
| Pitch | 10mm | |
| Current | 41A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.2mm² | |
| Mount Type | Through Hole | |
| Maximum Wire Size mm² | 6mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 10AWG | |
| Colour | Grey | |
| Wire Connection Method | Cage Clamp | |
| Voltage | 80V | |
| Width | 19.1mm | |
| Series | 745 | |
| Depth | 29.1mm | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 2 | ||
Product Type PCB Connector | ||
Pitch 10mm | ||
Current 41A | ||
Number of Rows 1 | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.2mm² | ||
Mount Type Through Hole | ||
Maximum Wire Size mm² 6mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 10AWG | ||
Colour Grey | ||
Wire Connection Method Cage Clamp | ||
Voltage 80V | ||
Width 19.1mm | ||
Series 745 | ||
Depth 29.1mm | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- PL
The Wago Terminal block is engineered to deliver an exceptional connection experience in electrical applications. With its CAGE CLAMP technology, it ensures secure and reliable connections while accommodating various conductor sizes. Designed with user convenience in mind, this product features double solder pins for enhanced mechanical stability and a compact footprint, making it ideal for tight spaces.
Double solder pins provide high mechanical stability
Accommodates multiple conductor sizes for versatile usage
Compliant with rigorous safety and environmental standards
Compatible with various marking systems for easy identification
