WAGO 745 Series PCB Connector, 3-Contact, 5 mm Pitch, Through Hole, 1 Row
- RS Stock No.:
- 222-464
- Mfr. Part No.:
- 745-103
- Brand:
- WAGO
Subtotal (1 box of 160 units)*
£308.66
(exc. VAT)
£370.39
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 28 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £308.66 | £1.929 |
*price indicative
- RS Stock No.:
- 222-464
- Mfr. Part No.:
- 745-103
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 3 | |
| Product Type | PCB Connector | |
| Pitch | 5mm | |
| Current | 32A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide 66 | |
| Mount Type | Through Hole | |
| Minimum Wire Size mm² | 0.08mm² | |
| Maximum Wire Size mm² | 4mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | 45° | |
| Wire Connection Method | Cage Clamp | |
| Colour | Grey | |
| Voltage | 32V | |
| Series | 745 | |
| Standards/Approvals | No | |
| Depth | 22.9mm | |
| Width | 16.5mm | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 3 | ||
Product Type PCB Connector | ||
Pitch 5mm | ||
Current 32A | ||
Number of Rows 1 | ||
Housing Material Polyamide 66 | ||
Mount Type Through Hole | ||
Minimum Wire Size mm² 0.08mm² | ||
Maximum Wire Size mm² 4mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation 45° | ||
Wire Connection Method Cage Clamp | ||
Colour Grey | ||
Voltage 32V | ||
Series 745 | ||
Standards/Approvals No | ||
Depth 22.9mm | ||
Width 16.5mm | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block is engineered for high reliability in varied electrical applications. Designed for seamless connections and easy installation, this model utilises CAGE CLAMP technology, ensuring excellent grip and stability even in dynamic environments. Crafted with intricate attention to detail, the terminal block features a compact design that accommodates up to three potentials, making it ideal for space-constrained applications.
Double solder pins enhance mechanical stability
Versions with Ex approval ensure suitability for hazardous environments
Marker slot accommodates Mini WSB markers for easy identification
Compatible with various connection types for versatile applications
