WAGO 2624 Series PCB Connector, 14-Contact, 5 mm Pitch, Feed Through, 1 Row
- RS Stock No.:
- 221-735
- Mfr. Part No.:
- 2624-3114
- Brand:
- WAGO
Subtotal (1 box of 35 units)*
£277.85
(exc. VAT)
£333.42
(inc. VAT)
Stock information currently inaccessible - Please check back later
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £277.85 | £7.939 |
*price indicative
- RS Stock No.:
- 221-735
- Mfr. Part No.:
- 2624-3114
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Product Type | PCB Connector | |
| Number of Contacts | 14 | |
| Pitch | 5mm | |
| Current | 41A | |
| Number of Rows | 1 | |
| Housing Material | Polyamide 66 | |
| Mount Type | Feed Through | |
| Minimum Wire Size mm² | 0.2mm² | |
| Maximum Wire Size mm² | 6mm² | |
| Minimum Wire Size AWG | 24AWG | |
| Maximum Wire Size AWG | 10AWG | |
| Orientation | Parallel Entry | |
| Wire Connection Method | Push-in Cage Clamp | |
| Colour | Grey | |
| Voltage | 630V | |
| Width | 71.5mm | |
| Standards/Approvals | No | |
| Depth | 15.4mm | |
| Series | 2624 | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Product Type PCB Connector | ||
Number of Contacts 14 | ||
Pitch 5mm | ||
Current 41A | ||
Number of Rows 1 | ||
Housing Material Polyamide 66 | ||
Mount Type Feed Through | ||
Minimum Wire Size mm² 0.2mm² | ||
Maximum Wire Size mm² 6mm² | ||
Minimum Wire Size AWG 24AWG | ||
Maximum Wire Size AWG 10AWG | ||
Orientation Parallel Entry | ||
Wire Connection Method Push-in Cage Clamp | ||
Colour Grey | ||
Voltage 630V | ||
Width 71.5mm | ||
Standards/Approvals No | ||
Depth 15.4mm | ||
Series 2624 | ||
- COO (Country of Origin):
- PL
The Wago PCB terminal block with Push-in CAGE CLAMP connection is designed to streamline your wiring needs while ensuring reliable performance. This versatile component accommodates solid as well as fine-stranded conductors, making it ideal for various panel feedthrough applications. Featuring a 14-pole configuration with 5 mm pin spacing, this terminal block promotes ease of use and safety.
Complies with industry standards for safety and performance
Lightweight yet durable facilitating panel layouts without hassle
Environmentally compliant adhering to RoHS regulations
