WAGO 255 Series PCB Connector, 2-Contact, 10.16 mm Pitch, 2 Row, 255-602
- RS Stock No.:
- 220-788
- Mfr. Part No.:
- 255-602
- Brand:
- WAGO
Subtotal (1 box of 50 units)*
£36.87
(exc. VAT)
£44.24
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 12 June 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Box(es) | Per Box | Per unit* |
|---|---|---|
| 1 + | £36.87 | £0.737 |
*price indicative
- RS Stock No.:
- 220-788
- Mfr. Part No.:
- 255-602
- Brand:
- WAGO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | WAGO | |
| Number of Contacts | 2 | |
| Product Type | PCB Connector | |
| Pitch | 10.16mm | |
| Number of Rows | 2 | |
| Housing Material | Polyamide 66 | |
| Minimum Wire Size mm² | 0.08mm² | |
| Connector Gender | Male | |
| Maximum Wire Size mm² | 2.5mm² | |
| Minimum Wire Size AWG | 28AWG | |
| Maximum Wire Size AWG | 12AWG | |
| Orientation | 90° | |
| Wire Connection Method | Cage Clamp | |
| Colour | Grey | |
| Series | 255 | |
| Width | 22.9mm | |
| Depth | 18.3mm | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand WAGO | ||
Number of Contacts 2 | ||
Product Type PCB Connector | ||
Pitch 10.16mm | ||
Number of Rows 2 | ||
Housing Material Polyamide 66 | ||
Minimum Wire Size mm² 0.08mm² | ||
Connector Gender Male | ||
Maximum Wire Size mm² 2.5mm² | ||
Minimum Wire Size AWG 28AWG | ||
Maximum Wire Size AWG 12AWG | ||
Orientation 90° | ||
Wire Connection Method Cage Clamp | ||
Colour Grey | ||
Series 255 | ||
Width 22.9mm | ||
Depth 18.3mm | ||
Standards/Approvals No | ||
- COO (Country of Origin):
- CH
The Wago PCB Terminal Block is designed not only for practical functionality but also for ease of use, featuring push button actuation for tool free operation. Ideal for a variety of applications, its innovative CAGE CLAMP connection technology ensures secure and reliable connections, supporting both solid and fine stranded conductors. The terminal block accommodates different conductor sizes while maintaining compliance with stringent international standards.
Compact form factor maximises PCB layout efficiency
Constructed with premium materials for enhanced durability
Available in multiple configurations to suit diverse requirements
Environmentally compliant ensuring responsible use in applications
Designed for both metric and inch pin spacing variation
