HARWIN M80 Series Vertical PCB PCB Socket, 10-Contact, 2 Row, 2 mm Pitch Crimp
- RS Stock No.:
- 287-1063
- Mfr. Part No.:
- M80-5101022
- Brand:
- HARWIN
Get a bulk buy discount
Add 26 more to save 3%
View bulk pricing optionsSubtotal (1 tube of 13 units)*
£132.81
(exc. VAT)
£159.37
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 12 March 2027
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tube* | Saving |
|---|---|---|---|
| 13 - 13 | £10.216 | £132.81 | - |
| 26 - 26 | £9.808 | £127.50 | 3% |
| 39 - 39 | £9.431 | £122.60 | 7% |
| 52 - 52 | £9.081 | £118.05 | 11% |
| 65 + | £8.756 | £113.83 | 14% |
*price indicative
- RS Stock No.:
- 287-1063
- Mfr. Part No.:
- M80-5101022
- Brand:
- HARWIN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARWIN | |
| Product Type | PCB Socket | |
| Number of Contacts | 10 | |
| Sub Type | Through Board Connector | |
| Number of Rows | 2 | |
| Current | 3A | |
| Pitch | 2mm | |
| Termination Type | Crimp | |
| Housing Material | PPS | |
| Mount Type | PCB | |
| Orientation | Vertical | |
| Voltage | 800V | |
| Series | M80 | |
| Minimum Operating Temperature | -55°C | |
| Row Pitch | 2mm | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 125°C | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Gold | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand HARWIN | ||
Product Type PCB Socket | ||
Number of Contacts 10 | ||
Sub Type Through Board Connector | ||
Number of Rows 2 | ||
Current 3A | ||
Pitch 2mm | ||
Termination Type Crimp | ||
Housing Material PPS | ||
Mount Type PCB | ||
Orientation Vertical | ||
Voltage 800V | ||
Series M80 | ||
Minimum Operating Temperature -55°C | ||
Row Pitch 2mm | ||
Contact Gender Male | ||
Maximum Operating Temperature 125°C | ||
Contact Material Phosphor Bronze | ||
Contact Plating Gold | ||
Standards/Approvals RoHS | ||
RoHS Status: Not Applicable
- COO (Country of Origin):
- GB
The HARWIN J-Tek DIL Throughboard Connector has gold finish on contact area and Tin finish on termination. It has slotted nuts provided for assembly to board mount stud.
Highly reliable
RoHS compliant
