HARWIN G125 Series Horizontal PCB PCB Socket, 10-Contact, 2 Row, 1.25 mm Pitch Solder
- RS Stock No.:
- 287-0989
- Mfr. Part No.:
- G125-MH11005L1P
- Brand:
- HARWIN
Bulk discount available
Subtotal (1 tape of 10 units)*
£62.10
(exc. VAT)
£74.50
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- 80 unit(s) shipping from 23 July 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Tape* |
|---|---|---|
| 10 - 10 | £6.21 | £62.10 |
| 20 - 20 | £5.961 | £59.61 |
| 30 - 30 | £5.732 | £57.32 |
| 40 - 40 | £5.521 | £55.21 |
| 50 + | £5.322 | £53.22 |
*price indicative
- RS Stock No.:
- 287-0989
- Mfr. Part No.:
- G125-MH11005L1P
- Brand:
- HARWIN
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | HARWIN | |
| Product Type | PCB Socket | |
| Number of Contacts | 10 | |
| Sub Type | Through Board Connector | |
| Number of Rows | 2 | |
| Pitch | 1.25mm | |
| Current | 2.8A | |
| Termination Type | Solder | |
| Housing Material | Polyamide | |
| Mount Type | PCB | |
| Orientation | Horizontal | |
| Series | G125 | |
| Row Pitch | 1.25mm | |
| Minimum Operating Temperature | -65°C | |
| Maximum Operating Temperature | 150°C | |
| Contact Gender | Male | |
| Contact Plating | Gold | |
| Contact Material | Phosphor Bronze | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand HARWIN | ||
Product Type PCB Socket | ||
Number of Contacts 10 | ||
Sub Type Through Board Connector | ||
Number of Rows 2 | ||
Pitch 1.25mm | ||
Current 2.8A | ||
Termination Type Solder | ||
Housing Material Polyamide | ||
Mount Type PCB | ||
Orientation Horizontal | ||
Series G125 | ||
Row Pitch 1.25mm | ||
Minimum Operating Temperature -65°C | ||
Maximum Operating Temperature 150°C | ||
Contact Gender Male | ||
Contact Plating Gold | ||
Contact Material Phosphor Bronze | ||
Standards/Approvals RoHS | ||
- COO (Country of Origin):
- GB
The HARWIN DIL Male 3.3mm Throughboard Connector is a PC Tail connector, Latches with through-hole barbs for 1.6mm PCB thickness, 10 contacts (5+5). Its through-hole barbs can be used as location pegs, or soldered to PCB for additional strain relief.
RoHS compliant
Polarizing feature
