Wurth Elektronik WR-WTB Series Vertical Surface PCB Socket, 8-Contact, 1 Row Surface Mount
- RS Stock No.:
- 205-3243
- Mfr. Part No.:
- 665308124022
- Brand:
- Wurth Elektronik
Subtotal (1 reel of 1000 units)*
£683.00
(exc. VAT)
£820.00
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 01 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 1000 + | £0.683 | £683.00 |
*price indicative
- RS Stock No.:
- 205-3243
- Mfr. Part No.:
- 665308124022
- Brand:
- Wurth Elektronik
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Wurth Elektronik | |
| Product Type | PCB Socket | |
| Number of Contacts | 8 | |
| Sub Type | SMT Male Vertical Shrouded Header | |
| Number of Rows | 1 | |
| Current | 3A | |
| Termination Type | Surface Mount | |
| Housing Material | Polybutylene Terephthalate | |
| Mount Type | Surface | |
| Orientation | Vertical | |
| Connector System | Board-to-Board | |
| Voltage | 500 V | |
| Series | WR-WTB | |
| Row Pitch | 2.54mm | |
| Minimum Operating Temperature | -40°C | |
| Contact Material | Copper Alloy | |
| Contact Gender | Female | |
| Maximum Operating Temperature | 105°C | |
| Contact Plating | Gold | |
| Standards/Approvals | No | |
| Select all | ||
|---|---|---|
Brand Wurth Elektronik | ||
Product Type PCB Socket | ||
Number of Contacts 8 | ||
Sub Type SMT Male Vertical Shrouded Header | ||
Number of Rows 1 | ||
Current 3A | ||
Termination Type Surface Mount | ||
Housing Material Polybutylene Terephthalate | ||
Mount Type Surface | ||
Orientation Vertical | ||
Connector System Board-to-Board | ||
Voltage 500 V | ||
Series WR-WTB | ||
Row Pitch 2.54mm | ||
Minimum Operating Temperature -40°C | ||
Contact Material Copper Alloy | ||
Contact Gender Female | ||
Maximum Operating Temperature 105°C | ||
Contact Plating Gold | ||
Standards/Approvals No | ||
The Wurth Elektronik WR-WTB series surface mount male PCB socket header connector with a 1mm pitch. This board to board header has a beige UL94-V0 PBT insulator and stamped tin plated phosphor bronze contacts.
Pins = 8
Type = vertical
Insulator flammability rating = UL94 V-0
Operating temperature = -40°C and 105 °C
