Amphenol Industrial SSL12 Series Straight Surface PCB Socket, 2-Contact, 1 Row, 20 mm Pitch Solder
- RS Stock No.:
- 174-9474
- Mfr. Part No.:
- SSL12-J2D00-000001
- Brand:
- Amphenol Industrial
Subtotal (1 reel of 5 units)*
£3.68
(exc. VAT)
£4.415
(inc. VAT)
FREE delivery for orders over £60.00
Temporarily out of stock
- Shipping from 05 October 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units | Per unit | Per Reel* |
|---|---|---|
| 5 + | £0.736 | £3.68 |
*price indicative
- RS Stock No.:
- 174-9474
- Mfr. Part No.:
- SSL12-J2D00-000001
- Brand:
- Amphenol Industrial
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Amphenol Industrial | |
| Product Type | PCB Socket | |
| Number of Contacts | 2 | |
| Number of Rows | 1 | |
| Pitch | 20mm | |
| Current | 5A | |
| Housing Material | Thermoplastic | |
| Termination Type | Solder | |
| Mount Type | Surface | |
| Orientation | Straight | |
| Connector System | Board-to-Cable | |
| Voltage | 250V ac/dc | |
| Series | SSL12 | |
| Row Pitch | 2mm | |
| Minimum Operating Temperature | -40°C | |
| Contact Plating | Gold | |
| Maximum Operating Temperature | 105°C | |
| Contact Material | Copper Alloy | |
| Contact Gender | Male | |
| Standards/Approvals | RoHS | |
| Select all | ||
|---|---|---|
Brand Amphenol Industrial | ||
Product Type PCB Socket | ||
Number of Contacts 2 | ||
Number of Rows 1 | ||
Pitch 20mm | ||
Current 5A | ||
Housing Material Thermoplastic | ||
Termination Type Solder | ||
Mount Type Surface | ||
Orientation Straight | ||
Connector System Board-to-Cable | ||
Voltage 250V ac/dc | ||
Series SSL12 | ||
Row Pitch 2mm | ||
Minimum Operating Temperature -40°C | ||
Contact Plating Gold | ||
Maximum Operating Temperature 105°C | ||
Contact Material Copper Alloy | ||
Contact Gender Male | ||
Standards/Approvals RoHS | ||
- COO (Country of Origin):
- CN
The Amphenol SSL12 series, 2 pins, snap in with latch, SSL1. 2 connector. It has jack connector gender with current rating of 5A and voltage rating of 250V.
IP68, mated waterproof rating, 1M depth of water in 24 hours
High temperature thermoplastic housing
Copper alloy, gold plated terminal
Temperature ranges between -40℃ to 105℃
