Molex KK 396 Series Straight Through Hole Pin Header, 24 Contact(s), 3.96 mm Pitch, 1 Row(s), Unshrouded

View all PCB Headers
Bulk discount available

Subtotal (1 pack of 5 units)*

£11.01

(exc. VAT)

£13.21

(inc. VAT)

Add to Basket
Select or type quantity
In Stock
  • 320 unit(s) ready to ship
  • Plus 20 unit(s) ready to ship from another location
  • Plus 1,260 unit(s) shipping from 24 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Units
Per unit
Per Pack*
5 - 95£2.202£11.01
100 - 370£1.532£7.66
375 - 1495£1.472£7.36
1500 - 2995£1.276£6.38
3000 +£1.224£6.12

*price indicative

Packaging Options:
RS Stock No.:
173-3048
Mfr. Part No.:
26-48-1245
Brand:
Molex
Find similar products by selecting one or more attributes.
Select all

Brand

Molex

Series

KK 396

Product Type

Pin Header

Current

7A

Pitch

3.96mm

Number of Contacts

24

Housing Material

Polyester

Number of Rows

1

Orientation

Straight

Shrouded/Unshrouded

Unshrouded

Mount Type

Through Hole

Connector System

Wire-to-Board

Contact Material

Brass

Contact Plating

Tin

Row Pitch

3.96mm

Termination Type

Solder

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

105°C

Tail Pin Length

4.37mm

Contact Gender

Male

Standards/Approvals

No

Voltage

250 V

Distrelec Product Id

304-30-631

KK 396 Headers, 41671 and 41672 Series


A range of KK 396 Breakaway Headers with Square Pins and Friction Locks.

Mates with 3069; 2139; 6442 and 41695 Series housings, 7674 and 7675 Series IDT connectors, 41815; 2145 and 3215 Series PCB connectors.

3.96mm Molex KK Range


Approvals

UL (E29179); CSA (LR19980)
