Molex 42492 Series Right Angled Through Hole PCB Header, 12 Contact(s), 3.96mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 bag of 200 units)*

£196.93

(exc. VAT)

£236.32

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible
Bag(s)
Per Bag
Per unit*
1 +£196.93£0.985

*price indicative

RS Stock No.:
684-856
Mfr. Part No.:
26-64-5120
Brand:
Molex
Find similar products by selecting one or more attributes.
Select all

Brand

Molex

Series

42492

Pitch

3.96mm

Number of Contacts

12

Number of Rows

1

Body Orientation

Right Angled

Shrouded/Unshrouded

Shrouded

Mounting Type

Through Hole

COO (Country of Origin):
IN
The Molex KK 396 Header designed as a reliable connector solution for power and wire-to-board applications. Its right-angle configuration offers flexibility in PCB design, accommodating space-efficient setups while providing robust connectivity. Engineered with 12 circuits, this connector ensures maximum performance through its durable construction and tin plating. The KK 396 Header meets various industry compliance standards, making it suitable for diverse environments. With an operational temperature range and excellent mating durability, this connector not only simplifies assembly but also guarantees a long-lasting connection for your electronic projects.

Active status ensures up to date performance and reliability
Designed with a right angle orientation for efficient space utilisation
Constructed with high quality brass and tin plating for superior conductivity
Capable of 12 loaded circuits for versatile applications
Features a through hole termination interface for reliable mounting
Includes PCB retention capabilities for added security during operation
Endures a durability of up to 25 mating cycles, ensuring longevity
Meets EU RoHS compliance for environmentally friendly use
