Molex 2599 Series Vertical PCB Mount PCB Header, 7 Contact(s), 5.08mm Pitch, 1 Row(s), Shrouded, Unshrouded
- RS Stock No.:
- 684-796
- Mfr. Part No.:
- 10-08-5071
- Brand:
- Molex
Subtotal (1 bag of 250 units)*
£180.22
(exc. VAT)
£216.26
(inc. VAT)
Stock information currently inaccessible
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 + | £180.22 | £0.721 |
*price indicative
- RS Stock No.:
- 684-796
- Mfr. Part No.:
- 10-08-5071
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Series | 2599 | |
| Pitch | 5.08mm | |
| Number of Contacts | 7 | |
| Number of Rows | 1 | |
| Body Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded, Unshrouded | |
| Mounting Type | PCB Mount | |
Select all | ||
|---|---|---|
Brand Molex | ||
Series 2599 | ||
Pitch 5.08mm | ||
Number of Contacts 7 | ||
Number of Rows 1 | ||
Body Orientation Vertical | ||
Shrouded/Unshrouded Shrouded, Unshrouded | ||
Mounting Type PCB Mount | ||
- COO (Country of Origin):
- IN
The Molex KK Header, Vertical, with Polarizing Backwall, is engineered to facilitate reliable wire-to-board connections in diverse electronic applications. With its robust design featuring 7 circuits and tin plating, this component is crafted to ensure durable performance and secure connectivity, making it an essential choice for PCB headers and receptacles. Designed with the user in mind, it supports a maximum current of 7.0A and a voltage of 250V, ensuring capabilities suited for various power applications. The header's compatibility with multiple housings and connectors offers flexible integration opportunities within various electronic systems, enhancing both functionality and ease of assembly.
Active product status guarantees availability for immediate use
Versatile application for power and wire to board connections
Compact design with a vertical orientation suitable for space constrained PCB layouts
Durability ensured with 25 mating cycles, enhancing longevity
Natural resin colour for a discreet yet professional appearance
No breakaway feature aligns with secure mounting requirements
Meets UL certification standards, promising safety and dependability
Low hazard materials support compliance with environmental regulations
Efficient through hole termination interface style simplifies installation
Stackable design optimises space and improves circuit density
Versatile application for power and wire to board connections
Compact design with a vertical orientation suitable for space constrained PCB layouts
Durability ensured with 25 mating cycles, enhancing longevity
Natural resin colour for a discreet yet professional appearance
No breakaway feature aligns with secure mounting requirements
Meets UL certification standards, promising safety and dependability
Low hazard materials support compliance with environmental regulations
Efficient through hole termination interface style simplifies installation
Stackable design optimises space and improves circuit density
