Molex 4094 Series Right Angle Through Hole PCB Header, 14 Contact(s), 2.54mm Pitch, 1 Row(s), Unshrouded
- RS Stock No.:
- 684-435
- Mfr. Part No.:
- 22-05-2141
- Brand:
- Molex
Subtotal (1 bag of 300 units)*
£205.71
(exc. VAT)
£246.85
(inc. VAT)
Stock information currently inaccessible
Bag(s) | Per Bag | Per unit* |
---|---|---|
1 + | £205.71 | £0.686 |
*price indicative
- RS Stock No.:
- 684-435
- Mfr. Part No.:
- 22-05-2141
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Molex | |
Series | 4094 | |
Pitch | 2.54mm | |
Number of Contacts | 14 | |
Number of Rows | 1 | |
Body Orientation | Right Angle | |
Shrouded/Unshrouded | Unshrouded | |
Mounting Type | Through Hole | |
Select all | ||
---|---|---|
Brand Molex | ||
Series 4094 | ||
Pitch 2.54mm | ||
Number of Contacts 14 | ||
Number of Rows 1 | ||
Body Orientation Right Angle | ||
Shrouded/Unshrouded Unshrouded | ||
Mounting Type Through Hole | ||
- COO (Country of Origin):
- IN
The Molex KK 254 Wire-to-Board Header designed for reliable connectivity in various electronic applications. Ideal for board-to-board, signal, and wire-to-board interfacing, this single-row header accommodates 14 circuits with a right-angle orientation. Constructed from durable PA polyamide nylon and featuring tin (Sn) plating, it ensures excellent performance even in demanding environments. With a current rating of 4.0A and a maximum voltage of 500V, it is suitable for a wide range of signals. The product's low-halogen compliance and RoHS certification also signal its commitment to environmental standards, making it a dependable choice for modern electronic designs.
Single row design optimises board space and simplifies layouts
Right angle orientation facilitates efficient space management in tight configurations
Durable polyamide nylon construction supports robust and long lasting connections
Tin plating on metal components enhances solderability and conductivity
Compatible with through hole termination style for reliable fixed connections
14 circuits provide versatile connectivity options for complex assemblies
Low halogen and RoHS compliant, ensuring alignment with environmental regulations
Durability rated for 25 mating cycles, ensuring reliability over multiple uses
Right angle orientation facilitates efficient space management in tight configurations
Durable polyamide nylon construction supports robust and long lasting connections
Tin plating on metal components enhances solderability and conductivity
Compatible with through hole termination style for reliable fixed connections
14 circuits provide versatile connectivity options for complex assemblies
Low halogen and RoHS compliant, ensuring alignment with environmental regulations
Durability rated for 25 mating cycles, ensuring reliability over multiple uses
