Molex 215760 Series Right Angle Through Hole PCB Header Pin, 5 Contact(s), 3mm Pitch, 1 Row(s), Shrouded
- RS Stock No.:
- 684-425
- Mfr. Part No.:
- 215760-2005
- Brand:
- Molex
Subtotal (1 tray of 100 units)*
£200.45
(exc. VAT)
£240.54
(inc. VAT)
Stock information currently inaccessible
Tray(s) | Per Tray | Per unit* |
---|---|---|
1 + | £200.45 | £2.005 |
*price indicative
- RS Stock No.:
- 684-425
- Mfr. Part No.:
- 215760-2005
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Molex | |
Series | 215760 | |
Pitch | 3mm | |
Number of Contacts | 5 | |
Number of Rows | 1 | |
Body Orientation | Right Angle | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Through Hole | |
Select all | ||
---|---|---|
Brand Molex | ||
Series 215760 | ||
Pitch 3mm | ||
Number of Contacts 5 | ||
Number of Rows 1 | ||
Body Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Through Hole | ||
- COO (Country of Origin):
- CN
The Molex Micro-Fit+ Right-Angle Header is engineered for reliable power connections in wire-to-board applications. Designed with a precise 3.00mm pitch, this single-row component accommodates up to five circuits, making it ideal for compact electronic assemblies. Featuring a robust construction of high copper alloy with black liquid crystal polymer, the header ensures durability and longevity in various operating conditions, supporting a temperature range of -40° to +125°C. With a gold plating for optimal conductivity and compliance with stringent environmental standards, this trusty connector is the perfect solution for applications demanding high performance and safety.
Built to provide a reliable mating connection with lock mechanisms to secure contacts
Glow wire capability adds an extra layer of safety for electronic applications
Designed for durability with a mating cycle endurance of up to 200 cycles
Low halogen materials ensure environmental compliance and safety in sensitive applications
Polarised design ensures correct orientation and alignment during installation
Effective PCB retention feature secures connections during operation, enhancing dependability
Glow wire capability adds an extra layer of safety for electronic applications
Designed for durability with a mating cycle endurance of up to 200 cycles
Low halogen materials ensure environmental compliance and safety in sensitive applications
Polarised design ensures correct orientation and alignment during installation
Effective PCB retention feature secures connections during operation, enhancing dependability
