Molex 71308 Series Vertical Through Hole PCB Header, 24 Contact(s), 2.54mm Pitch, 2 Row(s), Unshrouded

View all PCB Headers

Subtotal (1 tube of 153 units)*

£215.20

(exc. VAT)

£258.24

(inc. VAT)

Add to Basket
Select or type quantity
Stock information currently inaccessible
Tube(s)
Per Tube
Per unit*
1 +£215.20£1.407

*price indicative

RS Stock No.:
684-229
Mfr. Part No.:
15-91-0240
Brand:
Molex
Find similar products by selecting one or more attributes.
Select all

Brand

Molex

Series

71308

Pitch

2.54mm

Number of Contacts

24

Number of Rows

2

Body Orientation

Vertical

Shrouded/Unshrouded

Unshrouded

Mounting Type

Through Hole

COO (Country of Origin):
MY
The Molex C-Grid 2.54mm Pitch Breakaway Header designed for efficient and reliable board-to-board and wire-to-board connections. This surface mount component features a dual-row configuration with 24 circuits, ensuring a robust connection in various applications. Built from high-temperature thermoplastic and plated with 0.38μm gold for mating, it meets stringent electrical specifications with a maximum current of 3.0A and can withstand voltage levels up to 250V. The C-Grid series stands out for its durability, boasting a mating cycle lifespan of up to 50 cycles while remaining compliant with EU RoHS regulations. With a vertical orientation, it is tailored for space-constrained designs, making it an excellent choice for modern electronics.

0.38μm gold plating on mating surfaces ensures optimal signal integrity
Meets EU RoHS compliance for environmentally responsible manufacturing
Durability is enhanced with a mating cycle rating of 50 cycles
Vertical orientation facilitates easier installation in compact spaces
