Molex 105312 Series Vertical Through Hole PCB Header, 10 Contact(s), 2.5 mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 684-054
- Mfr. Part No.:
- 105312-2110
- Brand:
- Molex
Subtotal (1 tray of 100 units)*
£198.68
(exc. VAT)
£238.42
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 13 May 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Tray(s) | Per Tray | Per unit* |
|---|---|---|
| 1 + | £198.68 | £1.987 |
*price indicative
- RS Stock No.:
- 684-054
- Mfr. Part No.:
- 105312-2110
- Brand:
- Molex
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | Molex | |
| Product Type | PCB Header | |
| Series | 105312 | |
| Pitch | 2.5mm | |
| Current | 8A | |
| Housing Material | Liquid Crystal Polymer | |
| Number of Contacts | 10 | |
| Number of Rows | 2 | |
| Orientation | Vertical | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Contact Plating | Tin | |
| Contact Material | Brass | |
| Row Pitch | 2.5mm | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Solder | |
| Tail Pin Length | 3.2mm | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | RoHS | |
| Voltage | 250 V | |
| Select all | ||
|---|---|---|
Brand Molex | ||
Product Type PCB Header | ||
Series 105312 | ||
Pitch 2.5mm | ||
Current 8A | ||
Housing Material Liquid Crystal Polymer | ||
Number of Contacts 10 | ||
Number of Rows 2 | ||
Orientation Vertical | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Contact Plating Tin | ||
Contact Material Brass | ||
Row Pitch 2.5mm | ||
Minimum Operating Temperature -40°C | ||
Termination Type Solder | ||
Tail Pin Length 3.2mm | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals RoHS | ||
Voltage 250 V | ||
- COO (Country of Origin):
- CN
The Molex Nano-Fit Vertical Header is expertly engineered for precision power distribution in various PCB applications. This component features a dual row configuration with 10 circuits designed to deliver an optimal connection in a compact footprint. With a 2.50mm pitch and through-hole termination style it simplifies soldering and enhances reliability in high-density environments. Constructed with natural liquid crystal polymer it meets stringent performance standards ensuring durability and safety. The Nano-Fit’s compatibility with multiple receptacle housings allows for versatile mating options making it ideal for wire to board applications. This header is also glow-wire capable underscoring its commitment to safety in demanding conditions.
Glow-wire capability ensures compliance with safety standards
Dual row configuration accommodates 10 circuits for versatile connectivity
Through-hole termination simplifies assembly and enhances reliability
Natural resin colour provides a clean aesthetic for finished assemblies
Keying and locking features ensure secure mating with compatible components
Offers compatibility with various Nano-Fit receptacle housings for flexibility in design
