Phoenix Contact CCA 2 Series Wave Soldering Mount PCB Header, 6 Contact(s), 5.08 mm Pitch, 1 Row(s), Shrouded

View all PCB Headers

Subtotal (1 pack of 330 units)*

£354.70

(exc. VAT)

£425.64

(inc. VAT)

Add to Basket
Select or type quantity
Temporarily out of stock
  • Shipping from 23 January 2026
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s)
Per Pack
Per unit*
1 +£354.70£1.075

*price indicative

RS Stock No.:
638-432
Mfr. Part No.:
1955073
Brand:
Phoenix Contact
Find similar products by selecting one or more attributes.
Select all

Brand

Phoenix Contact

Product Type

PCB Header

Series

CCA 2

Current

12A

Pitch

5.08mm

Number of Contacts

6

Housing Material

Liquid Crystal Polymer

Number of Rows

1

Shrouded/Unshrouded

Shrouded

Connector System

COMBICON MSTB 2.5

Mount Type

Wave Soldering Mount

Contact Plating

Tin Plated

Contact Material

Copper Alloy

Row Pitch

5.08mm

Minimum Operating Temperature

-40°C

Termination Type

Pin

Maximum Operating Temperature

100°C

Tail Pin Length

2.6mm

Contact Gender

Male

Mating Pin Length

2.6mm

Standards/Approvals

cULus, DIN EN 61760-1, IEC 60068-2-58, IEC 60112, REACH, RoHS, UL 94 V0, VDE

Voltage

32 V

COO (Country of Origin):
DE
The Phoenix Contact PCB Header is part of the COMBICON Connectors M product line. It is suitable for through-hole reflow, with a mounting type that supports both THR soldering and wave soldering. The pin layout is linear pinning, and the contact material is copper alloy. The surface is tin-plated, and the insulating material is LCP.

Designed for integration into the SMT soldering process

Maximum flexibility when it comes to device design which is one header for connectors with different connection technologies
