RS PRO XY121 Series Straight Through Hole PCB Header, 4 Contact(s), 3.5 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 631-136
- Brand:
- RS PRO
Bulk discount available
View bulk pricing optionsSubtotal (1 bag of 10 units)*
£37.20
(exc. VAT)
£44.64
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 50 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 - 4 | £37.20 | £3.72 |
| 5 + | £34.22 | £3.422 |
*price indicative
- RS Stock No.:
- 631-136
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Series | XY121 | |
| Product Type | PCB Header | |
| Pitch | 3.5mm | |
| Current | 7A | |
| Housing Material | PA66 | |
| Number of Contacts | 4 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Board-to-Board, Board-to-Wire | |
| Mount Type | Through Hole | |
| Contact Plating | Tin | |
| Contact Material | Phosphor Bronze | |
| Termination Type | Screwless | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 105°C | |
| Tail Pin Length | 3.5mm | |
| Contact Gender | Male | |
| Standards/Approvals | ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL | |
| Voltage | 300V | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Series XY121 | ||
Product Type PCB Header | ||
Pitch 3.5mm | ||
Current 7A | ||
Housing Material PA66 | ||
Number of Contacts 4 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Board-to-Board, Board-to-Wire | ||
Mount Type Through Hole | ||
Contact Plating Tin | ||
Contact Material Phosphor Bronze | ||
Termination Type Screwless | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 105°C | ||
Tail Pin Length 3.5mm | ||
Contact Gender Male | ||
Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL | ||
Voltage 300V | ||
- COO (Country of Origin):
- CN
RS PRO 4-Pin Shrouded PCB Header, 3.5 mm Pitch
This RS PRO PCB Header is designed for reliable electrical connections in board-to-board and board-to-wire applications. With a robust construction, it ensures secure connectivity and is Ideal for use in various industrial environments.
Features and Benefits
Board-to-Board and Board-to-Wire System: Offers versatile connectivity options for different configurations.
Male Contact Gender: Ensures compatibility with female connectors for secure connections.
Phosphor Bronze Contacts: Provides excellent conductivity and durability.
Tin Contact Plating: Enhances corrosion resistance and ensures long-lasting performance.
7 A Current Rating: Suitable for applications requiring moderate current levels.
PA66 Housing Material: Offers high mechanical strength and thermal stability.
Wide Operating Temperature Range (-40 °C to 105 °C): Suitable for use in diverse environmental conditions.
Through Hole Mount Type: Ensures strong mechanical retention on the PCB.
Shrouded Design: Provides protection against accidental contact and enhances safety.
Screwless Termination: Facilitates quick and easy installation without the need for additional tools.
Male Contact Gender: Ensures compatibility with female connectors for secure connections.
Phosphor Bronze Contacts: Provides excellent conductivity and durability.
Tin Contact Plating: Enhances corrosion resistance and ensures long-lasting performance.
7 A Current Rating: Suitable for applications requiring moderate current levels.
PA66 Housing Material: Offers high mechanical strength and thermal stability.
Wide Operating Temperature Range (-40 °C to 105 °C): Suitable for use in diverse environmental conditions.
Through Hole Mount Type: Ensures strong mechanical retention on the PCB.
Shrouded Design: Provides protection against accidental contact and enhances safety.
Screwless Termination: Facilitates quick and easy installation without the need for additional tools.
Applications
Industrial automation
Consumer electronics
Telecommunications equipment
Consumer electronics
Telecommunications equipment
Additional Information
Standards Approvals: Compliant with ANSI-ESD S20.20:2021, CE, REACH, and RoHS standards, ensuring safety and environmental responsibility.
Why RS PRO?
RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
