RS PRO XY121 Series Straight Through Hole PCB Header, 3 Contact(s), 3.5 mm Pitch, 1 Row, Shrouded
- RS Stock No.:
- 631-135
- Brand:
- RS PRO
Bulk discount available
View bulk pricing optionsSubtotal (1 bag of 10 units)*
£28.06
(exc. VAT)
£33.67
(inc. VAT)
FREE delivery for orders over £60.00
In Stock
- 50 unit(s) ready to ship
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 - 4 | £28.06 | £2.806 |
| 5 + | £25.82 | £2.582 |
*price indicative
- RS Stock No.:
- 631-135
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | PCB Header | |
| Series | XY121 | |
| Current | 7A | |
| Pitch | 3.5mm | |
| Number of Contacts | 3 | |
| Housing Material | PA66 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Connector System | Board-to-Board, Board-to-Wire | |
| Mount Type | Through Hole | |
| Contact Material | Phosphor Bronze | |
| Contact Plating | Tin | |
| Termination Type | Screwless | |
| Minimum Operating Temperature | -40°C | |
| Tail Pin Length | 3.5mm | |
| Contact Gender | Male | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL | |
| Voltage | 300V | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type PCB Header | ||
Series XY121 | ||
Current 7A | ||
Pitch 3.5mm | ||
Number of Contacts 3 | ||
Housing Material PA66 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Connector System Board-to-Board, Board-to-Wire | ||
Mount Type Through Hole | ||
Contact Material Phosphor Bronze | ||
Contact Plating Tin | ||
Termination Type Screwless | ||
Minimum Operating Temperature -40°C | ||
Tail Pin Length 3.5mm | ||
Contact Gender Male | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals ANSI-ESD S20.20:2021, CE, REACH, RoHS, UL | ||
Voltage 300V | ||
- COO (Country of Origin):
- CN
RS PRO PCB Header, 3.5 mm Pitch, 3 Contacts, Shrouded
This RS PRO PCB Header is designed for reliable electrical connections in various electronic applications. With a 3.5 mm pitch and 3 contacts, it is Ideal for board-to-board and board-to-wire connections, ensuring efficient power distribution and signal integrity. The shrouded design provides additional protection, making it suitable for demanding environments.
Features and Benefits
Board-to-Board and Board-to-Wire System: Offers versatile connectivity options for various applications
Male Contact Gender: Ensures compatibility with corresponding female connectors
Phosphor Bronze Contacts: Provides excellent conductivity and durability
Tin Contact Plating: Enhances corrosion resistance and ensures long-term reliability
7 A Current Rating: Supports high current applications
PA66 Housing Material: Offers robust mechanical strength and thermal stability
Wide Operating Temperature Range (-40 °C to 105 °C): Suitable for use in extreme environmental conditions
Through Hole Mount Type: Facilitates secure and stable mounting on PCBs
Screwless Termination: Allows for quick and easy installation without the need for additional tools
Male Contact Gender: Ensures compatibility with corresponding female connectors
Phosphor Bronze Contacts: Provides excellent conductivity and durability
Tin Contact Plating: Enhances corrosion resistance and ensures long-term reliability
7 A Current Rating: Supports high current applications
PA66 Housing Material: Offers robust mechanical strength and thermal stability
Wide Operating Temperature Range (-40 °C to 105 °C): Suitable for use in extreme environmental conditions
Through Hole Mount Type: Facilitates secure and stable mounting on PCBs
Screwless Termination: Allows for quick and easy installation without the need for additional tools
Applications
Industrial electronics
Consumer electronics
Automotive systems
Telecommunications
Consumer electronics
Automotive systems
Telecommunications
Additional Information
Complies with ANSI-ESD S20.20:2021, CE, REACH, and RoHS standards, ensuring safety and environmental compliance.
Why RS PRO?
RS PRO is the own brand of RS, offering professional quality products and solutions across all industries and technologies. Our product range is rigorously tested, inspected, and audited against demanding international standards to provide you with industrial-grade quality, at the right price. Making RS PRO your smart choice.
