RS PRO XY2500 Series Right Angle Through Hole PCB Header, 6 Contact(s), 1 Row(s), Shrouded
- RS Stock No.:
- 631-122
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 bag of 10 units)*
£24.45
(exc. VAT)
£29.34
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 50 unit(s) shipping from 17 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 - 4 | £24.45 | £2.445 |
| 5 + | £22.49 | £2.249 |
*price indicative
- RS Stock No.:
- 631-122
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | PCB Header | |
| Series | XY2500 | |
| Current | 15A | |
| Number of Contacts | 6 | |
| Housing Material | Polyamide 66 | |
| Number of Rows | 1 | |
| Orientation | Right Angle | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Contact Material | Brass | |
| Contact Plating | Tin Plated | |
| Termination Type | Solder | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | CE, RoHS, UL | |
| Voltage | 30 V | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type PCB Header | ||
Series XY2500 | ||
Current 15A | ||
Number of Contacts 6 | ||
Housing Material Polyamide 66 | ||
Number of Rows 1 | ||
Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Contact Material Brass | ||
Contact Plating Tin Plated | ||
Termination Type Solder | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals CE, RoHS, UL | ||
Voltage 30 V | ||
- COO (Country of Origin):
- CN
The RS Pro Horizontal Header Terminal is a Right angle mount closed end PCB terminal block headers with a 7.62mm pitch. These 7.62mm pluggable terminal block PCB header connectors have a 300V 15A electrical rating and green PA66 housings.
Low Mating Force
6 Way Terminal
RoHS and REACH compliant
