RS PRO XY2500 Series Straight Through Hole PCB Header, 2 Contact(s), 1 Row(s), Shrouded
- RS Stock No.:
- 631-117
- Brand:
- RS PRO
Bulk discount available
Subtotal (1 bag of 10 units)*
£34.01
(exc. VAT)
£40.81
(inc. VAT)
FREE delivery for orders over £50.00
In Stock
- Plus 50 unit(s) shipping from 24 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Bag(s) | Per Bag | Per unit* |
|---|---|---|
| 1 - 4 | £34.01 | £3.401 |
| 5 + | £31.29 | £3.129 |
*price indicative
- RS Stock No.:
- 631-117
- Brand:
- RS PRO
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
|---|---|---|
| Brand | RS PRO | |
| Product Type | PCB Header | |
| Series | XY2500 | |
| Current | 8A | |
| Housing Material | Polyamide 66 | |
| Number of Contacts | 2 | |
| Number of Rows | 1 | |
| Orientation | Straight | |
| Shrouded/Unshrouded | Shrouded | |
| Mount Type | Through Hole | |
| Contact Material | Brass Steel | |
| Contact Plating | Nickel Plated | |
| Minimum Operating Temperature | -40°C | |
| Termination Type | Screw | |
| Maximum Operating Temperature | 105°C | |
| Standards/Approvals | CE, RoHS, UL | |
| Voltage | 30 V | |
| Select all | ||
|---|---|---|
Brand RS PRO | ||
Product Type PCB Header | ||
Series XY2500 | ||
Current 8A | ||
Housing Material Polyamide 66 | ||
Number of Contacts 2 | ||
Number of Rows 1 | ||
Orientation Straight | ||
Shrouded/Unshrouded Shrouded | ||
Mount Type Through Hole | ||
Contact Material Brass Steel | ||
Contact Plating Nickel Plated | ||
Minimum Operating Temperature -40°C | ||
Termination Type Screw | ||
Maximum Operating Temperature 105°C | ||
Standards/Approvals CE, RoHS, UL | ||
Voltage 30 V | ||
- COO (Country of Origin):
- CN
The RS Pro Screw Terminal with Flange is a Right angle cable mount terminal block plug connectors with a 3.5 mm pitch, M2.0 screw flanges and a 300V 8A electrical rating. These 3.5mm cable mount pluggable terminal blocks have M2.0 rising cage clamp screw terminals. They accept a wire size range of 28 AWG to 16 AWG and green PA66 housings.
Low Mating Force
Low Profile
2 Way Terminal
RoHS and REACH compliant
