Phoenix Contact Right Angle Solder Mount PCB Header, 10 Contact(s), 3.81mm Pitch, 2 Row(s), Shrouded
- RS Stock No.:
- 566-231
- Mfr. Part No.:
- 1830431
- Brand:
- Phoenix Contact
Subtotal (1 pack of 50 units)*
£308.23
(exc. VAT)
£369.88
(inc. VAT)
FREE delivery for orders over £50.00
Temporarily out of stock
- Shipping from 25 November 2025
Need more? Click ‘Check delivery dates’ to find extra stock and lead times.
Pack(s) | Per Pack | Per unit* |
---|---|---|
1 + | £308.23 | £6.165 |
*price indicative
- RS Stock No.:
- 566-231
- Mfr. Part No.:
- 1830431
- Brand:
- Phoenix Contact
Specifications
Technical Reference
Legislation and Compliance
Product Details
Find similar products by selecting one or more attributes.
Select all | Attribute | Value |
---|---|---|
Brand | Phoenix Contact | |
Pitch | 3.81mm | |
Number of Contacts | 10 | |
Number of Rows | 2 | |
Body Orientation | Right Angle | |
Shrouded/Unshrouded | Shrouded | |
Mounting Type | Solder Mount | |
Select all | ||
---|---|---|
Brand Phoenix Contact | ||
Pitch 3.81mm | ||
Number of Contacts 10 | ||
Number of Rows 2 | ||
Body Orientation Right Angle | ||
Shrouded/Unshrouded Shrouded | ||
Mounting Type Solder Mount | ||
- COO (Country of Origin):
- DE
The Phoenix Contact PCB Header offers an impressive combination of design flexibility and superior electrical performance. Tailored for demanding applications, the product ensures reliable connections with its robust 1.5 mm² nominal cross section and a striking green colour. Designed with wave soldering in mind, it features a simple linear pin layout that allows for ease of assembly and integration into various hardware setups. The product line embodies phoenix contact's commitment to quality, making it an ideal choice for both industrial and commercial applications.
Constructed with WEEE and RoHS compliant materials
Ideal for multi row arrangements due to vertical connection capabilities
Provides 10 potentials over two rows optimising connection density
Ideal for multi row arrangements due to vertical connection capabilities
Provides 10 potentials over two rows optimising connection density
